Specifications
small block ice machine1.Quick Freezing
2.Easy to install
3.High efficiency
4.flow stability
Name: High efficiency good performance small block ice machine
General Information:
1. Daily capacity: from 1 ton to 100 tons per set/24 hours.
2. Weight of each block ice: 5kg, 10kg, 15kg, 20kg, 25kg, 30kg....50kg...100kg. We also can customize for you.
3. Installation and operation is very easy. We will deliver the machine mainly as three parts to you. All you need to do is to connect the cooling tower with the refrigeration unit and connect refrigeration unit with the brine tank.
4. We will deliver the machine together with manual book which will instruct you how to install the machine and also teach you how to solve the common mistakes to the machines.
5. For our products, we offer you 1 year quality guarantee after the installation of the machine in your factory and lifelong technical support.
Block ice making machine:
NO. |
Parameters |
Technical data |
||
1 |
Name |
Block Ice Machine of container |
||
2 |
Model |
JJMB10 |
||
3 |
Quantity |
1Units |
||
4 |
Daily output |
1ton/day |
||
5 |
Weight |
1200kg |
||
6 |
Measurement |
Machine |
Main machine:3000mm x 1400mm x 800mm |
|
Cooling Tower:1100mm×1450mm ( Φ x H) | ||||
Size of Ice Block |
80mmx150mmX500mm (5KG/block)
40pcs/time, 5times/day, total 200pcs of 5kg block ice. |
|||
Time for Ice Formed |
4.5hours |
|||
7 |
Block Ice Temperature |
-8C. |
||
8 |
Relative Humidity |
85% |
||
9 |
Supply water temperature |
16C. |
||
10 |
Max. Ambient Temperature |
+40C. |
||
11 |
Noise |
55dB |
||
12 |
Refrigerant |
R22 |
||
13 |
Evaporating temp. |
-10°C |
||
14 |
Condenser temp |
+40°C |
||
15 |
Necessary cooling capacity |
35.1KW |
||
16 |
Input water temp. |
18°C |
||
17 |
Ambient temp. |
40°C |
||
18 |
Compressor |
Model |
Scroll Compressor |
|
Brand name |
Copeland |
|||
Power |
3.69KW |
|||
19 |
Total Power of cooling tower |
1.87 KW |
||
20 |
Cooling Way |
Water-cooled / Air Cooled |
||
21 |
Cooling water flow |
8 m3/h |
||
22 |
Water consumption |
0.02m3/h |
||
23 |
Power of circulating water pump |
2.2 KW |
||
24 |
Voltage |
220V/380V-1Phase-50Hz |
||
25 |
ice block weight density |
900-950kg/m3 |
||
Product Features:
a. Bitzer/Copeland/Hanbell refrigeration system to guarantee performance;
b. Thick enough heat insulation for water tank;
c. Stainless steel / Aluminum alloy made ice module;
d. Customized ice size and cycle quantity;
e. Water/air cooling for choose;
f. Good appearance,easy operation and maintenance.
Main machine:
Ice Block :
Ice-making tank:
