Specifications
ice block maker1.different Ice blocks weight
2.Brand compressor
3.High efficiency
4.High stability
Name: Low consumption small ice block maker with Copeland Compressor
IDEAL ice block machine is a new type with high efficiency units, which mainly aiming at the Africa, Middle East and Oceania.
This machinery units adopt the integrated design, easy to install, just need connect the power.
The ice making tank adopt the Polyurethane foam technology, it have good viscosity performance,avoiding the defects of foam uneven.
It’s design according to the theoretic fluid, so the flow stability.
Specification: Low consumption small ice block maker with Copeland Compressor
NO. |
Parameters |
Technical data |
||
1 |
Name |
Block Ice Machine of container |
||
2 |
Model |
JJMB10 |
||
3 |
Quantity |
1Units |
||
4 |
Daily output |
1ton/day |
||
5 |
Weight |
1200kg |
||
6 |
Measurement |
Machine |
Main machine:3000mm x 1400mm x 800mm |
|
Cooling Tower:1100mm×1450mm ( Φ x H) | ||||
Size of Ice Block |
80mmx150mmX500mm (5KG/block)
40pcs/time, 5times/day, total 200pcs of 5kg block ice. |
|||
Time for Ice Formed |
4.5hours |
|||
7 |
Block Ice Temperature |
-8C. |
||
8 |
Relative Humidity |
85% |
||
9 |
Supply water temperature |
16C. |
||
10 |
Max. Ambient Temperature |
+40C. |
||
11 |
Noise |
55dB |
||
12 |
Refrigerant |
R22 |
||
13 |
Evaporating temp. |
-10°C |
||
14 |
Condenser temp |
+40°C |
||
15 |
Necessary cooling capacity |
35.1KW |
||
16 |
Input water temp. |
18°C |
||
17 |
Ambient temp. |
40°C |
||
18 |
Compressor |
Model |
Scroll Compressor |
|
Brand name |
Copeland |
|||
Power |
3.69KW |
|||
19 |
Total Power of cooling tower |
1.87 KW |
||
20 |
Cooling Way |
Water-cooled / Air Cooled |
||
21 |
Cooling water flow |
8 m3/h |
||
22 |
Water consumption |
0.02m3/h |
||
23 |
Power of circulating water pump |
2.2 KW |
||
24 |
Voltage |
220V/380V-1Phase-50Hz |
||
25 |
ice block weight density |
900-950kg/m3 |
||
Brine system block ice machine structure and application:
(1)Brine system block ice machine structure: refrigeration unit, brine tank (ice making tank), water cooling tower/ air cooling fan, and necessary components.
We will prepare the three in unit, you just need to connect the power and water pipes for the three parts. Pleas see the picture in the attachment.
(2) Daily production: 1 ton per day to 100 tons per day.
(3) Weight of block ice: 2.5kg,5kg, 10kg, 20kg…100kg, also can be done as your requirement.
(4) Power form supply: 380V/50HZ/3P (Can be customized based on your requirements), Refrigerant R22/R404a.
(5)Application: the block ice is use to reduce temperature, especially in Africa country where the power is not stable
and the climate temperature is high. When the power is off, people use the block ice to cooling the drinking and beverage.
And block ice is also used to keep fish fresh or crushed into small pieces to fresh vegetable and fruit.
Ice-making tank:
