Specifications
winch wireless remote control 12v 24v1.radio remote controller for cranes, hoists
2.single speed
3.CE Rohs
Hot sell new crane remote control
winch wireless remote control 12v 24v
winch wireless remote control 12v 24v
Transmitter | |
Model |
WR21-E1B |
Single-speed button |
6 |
Double-speed button |
0 |
Emergency button |
NO |
Shell material |
ABS enhanced plastic |
Battery |
2pcs AA battery |
Battery life |
>100 hours |
Frequency |
400-460MHz |
Power |
<10mW |
Modulation system |
FM |
Control distance |
100m in ordinary conditions |
IP rating |
IP65 |
Size |
16.4*7.5*4.6cm |
Weight |
around 320g |
winch wireless remote control 12v 24v
Receiver | |
Model |
WR21-E1B |
Working voltage |
DC12/24V; AC85-400V |
Connection mode |
pin insert terminal block |
Relay capacity |
10A 250V |
Responding time |
<100ms |
Ambient temperature |
-20-70 degree |
IP rating |
IP65 |
Antenna |
External |
Size |
18.5*8.5*8.5cm |
Weight |
550g |
winch wireless remote control 12v 24v
winch wireless remote control 12v 24v
Standard Configuration:
* It suitable for single hook single speed electric hoist type crane and the application of under 8 contacts
* industrial remote control.
* One Transmitter 1pcs(with straps);
* One Receiver;
* One Receiver with 1meter cable ;
* Operation and Maintenance manual;
>> Wiring diagram
--------------------------------------------------------------------------------------------
winch wireless remote control 12v 24v
Package include:
Transmitter x1 (with strap)
Receiver x1 (receiver comes with 1 m connection cable)
Operation and maintenance manual x1
winch wireless remote control 12v 24v
winch wireless remote control 12v 24v winch wireless remote control 12v 24v
Technical Parameters:
F21-E1BInstruction:
winch wireless remote control 12v 24v
1. Depress the TX Emergency Stop or remove the magnetic key (for
F21-E1B without a Mushroom style stop button that stays
depressed, please hold down the STOP pushbutton)
2. Press UP pushbutton and hold it.
3. Start the system as usual.
winch wireless remote control 12v 24v
Design features:
1 |
• 2~6 commands (Pocket size transmitter : F21-2S/D) |
2 |
• Low cost for electronic chain hoist/monorail |
3 |
• Low power consumption transmitter. 2 AA batteries last up to 4 months |
4 |
• Extra shock resistant relay specially for mobile devices .(DC model only) |
5 |
• Over 4.3 billions unique ID code available. |
6 |
• Temperature range -35°C ~ +85°C |
7 |
• Enclosure protection class IP 65 |
8 |
• Microsoft Windows based software for easy customize configuration |
9 |
• Structure : Glass-Fiber |
Application:
The ranges of applications of our industrial radio remote control system
1. overhead bridge cranes,
2. gantry crane
3. beam launcher
4. monorail hoists,
5. motorized jib cranes o
6. Other pieces of industrial equipment.
winch wireless remote control 12v 24v
ABOUT WERUN :
Our company integrated with science, research, production, sales and service together.
We have had ISO,CE and ROHS certification. So far, our main product was low voltage appliance, radio remote control and led light.
With our work hard and develop continuously, we have had professional sales team, Engineers team, market specialist,ect.
Afterwards, we invested a lot and devoted ourselves into developing led light in 2007.
That is a “green” product. Last year, we combined the technology of radio remote control with led light
and invented a new kind of product that “PWM” Intelligent & wireless dimming led light.
Until now, our markets have been developed to oversea for better quality and better service.
Now, we sincerely wish more and more people join in ours coming true that the green” light lights up the world.
Finally, we have convenient traffic and warmly welcome you to visit ours.
winch wireless remote control 12v 24v
winch wireless remote control 12v 24v
winch wireless remote control 12v 24v
