CE Approved Radio Remote Control

CE Approved Radio Remote Control thumbnail-1
CE Approved Radio Remote Control photo-1
US$ 65 - 75 MOQ: 1 Unit
Key Specifications
Get Latest Price
Brand Name:
WECAN
Model Number:
WR21-E1B
Use:
Universal
Contact Supplier Request Quote Chat Now
Wenzhou Werun Electric Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI/NINGBO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name WECAN
Model Number WR21-E1B
Use Universal
Place of Origin Zhejiang, China

CE approved radio remote control

Transmitter

Model

WR21-E1B

Single-speed button

6

Double-speed button

0

Emergency button

NO

Shell material

ABS enhanced plastic

Battery

2pcs AA battery

Battery life

>100 hours

Frequency

400-460MHz

Power

<10mW

Modulation system

FM

Control distance

100m in ordinary conditions

IP rating

IP65

Size

16.4*7.5*4.6cm

Weight

around 320g

 CE approved radio remote control



Receiver

Model

WR21-E1B

Working voltage

DC12/24V; AC85-400V

Connection mode

pin insert terminal block

Relay capacity

10A 250V

Responding time

<100ms

Ambient temperature

-20-70 degree

IP rating

IP65

Antenna

External

Size

18.5*8.5*8.5cm

Weight

550g

 CE approved radio remote control



Standard Configuration:

* It suitable for single hook single speed electric hoist type crane and the application of under 8 contacts

* industrial remote control.

* One Transmitter 1pcs(with straps);

* One Receiver;

* One Receiver with 1meter cable ;

* Operation and Maintenance manual;

 >> Wiring diagram

--------------------------------------------------------------------------------------------

CE approved radio remote control



Package include:

 Transmitter x1 (with strap)
Receiver x1 (receiver comes with 1 m connection cable)
Operation and maintenance manual x1

 CE approved radio remote controlCE approved radio remote controlCE approved radio remote control

Technical Parameters:



CE approved radio remote control

 F21-E1BInstruction:



1. Depress the TX Emergency Stop or remove the magnetic key (for
F21-E1B without a Mushroom style stop button that stays
depressed, please hold down the STOP pushbutton)
2. Press UP pushbutton and hold it.
3. Press DOWN pushbutton 4 times and release “STOP & UP”
pushbutton when red LED flash.
4. Start the system as usual.





Design features





1

• 2~6 commands (Pocket size transmitter : F21-2S/D)

2

 • Low cost for electronic chain hoist/monorail

3

 • Low power consumption transmitter. 2 AA batteries last up to 4 months

4

 • Extra shock resistant relay specially for mobile devices .(DC model only)

5

 • Over 4.3 billions unique ID code available.

6

 • Temperature range -35°C ~ +85°C

7

 • Enclosure protection class IP 65

8

 • Microsoft Windows based software for easy customize configuration

9

 • Structure : Glass-Fiber





Application:

The ranges of applications of our industrial radio remote control system

1. overhead bridge cranes,

2. gantry crane

3. beam launcher

4. monorail hoists,

5. motorized jib cranes o

6. Other pieces of industrial equipment.
