Help CenterST Single Chamber High Pressure Gas Quenching Vacuum Furnace
Related Products
-
800*800*1200mm High Temp Sintering FurnaceUS$ 5,960 - 15,900MOQ: 1 Set -
Industrial Vacuum Furnace With High Pressure up to 1600degreeUS$ 9,100 - 16,000MOQ: 1 Set
-
1300C Annealing Furnace Used for Solid Solution AgeingUS$ 2,560 - 8,000MOQ: 1 Set
-
ST High Pressure Gas Cooling Molde Steel Heat Treatment FurnacesUS$ 9,800 - 25,600MOQ: 1 Set
-
1300 Degree C Heat Treatment Annealing Furnace With 900*900*1200mmUS$ 6,300 - 12,000MOQ: 1 Set
Chamber High Pressure Gas Quenching Vacuum Furnace
1.SiC heater
2.Ultimate vacuum degree: about 2Pa
3.Capacity:50~1500kg
ST- series of single chamber high pressure gas quenching furnace consists of furnace body, vacuum system, water cooling system, gas inflation system, gas cooling system, electric control system and furnace outer material car etc. It is used for high pressure gas quenching of materials like high-speed steel, tool & mould steel, high temperature alloy, martensitic stainless steel, titanium alloy ,etc., and also for annealing magnetic material. It has special compacted inner furnace structure, with high-efficiency heat exchanger; it uses inside 360-degree nozzle all around cooling method and the highest gas quenching pressure can reach up to 1MPa. It is configured with optimization designed gas quenching system and electric control system and there is little deformation of components
Main speicification:
Type |
ST-CVDQ -223 |
ST-CVDQ -335 |
ST-CVDQ -447 |
ST-CVDQ -669 |
ST-CVDQ -7712 |
ST-CVDQ -8812 |
ST-CVDQ -9912 |
ST-CVDQ -101015 |
Power |
30Kw |
57Kw |
75Kw |
140Kw |
200Kw |
250Kw |
300Kw |
350Kw |
Loading Capacity |
50Kg |
100Kg |
200Kg |
500Kg |
700Kg |
800Kg |
1000Kg |
1500Kg |
|
Effective heating zone (W*H*L) |
200*200*300mm |
300*300*500mm |
450*400*670mm |
600*600*900mm |
700*700*1200mm |
800*800*1200mm |
900*900*1200mm |
1000*1000*1500mm |
Utmost vacuum degree |
2*0.1Pa 4*0.001Pa |
2*0.1Pa 4*0.001Pa |
2*0.1Pa 4*0.001Pa |
2*0.1Pa 4*0.001Pa |
2*0.1Pa 4*0.001Pa |
2*0.1Pa 4*0.001Pa |
2*0.1Pa 4*0.001Pa |
2*0.1Pa 4*0.001Pa |
Highest temperature |
1350°C |
1350°C |
1350°C |
1350°C |
1350°C |
1400°C |
1400°C |
1400°C |
Gas quenching pressure |
2Bar |
2Bar |
2Bar |
2Bar |
2,4,6Bar |
2,4,6Bar |
2,4, 6,10Bar |
2,4, 6,10Bar |
Furnace temp uniformity |
±5°C |
±5°C |
±5°C |
±5°C |
±5°C |
±5°C |
±5°C |
±5°C |
Pressure increasing rate |
0.65Pa/h |
0.65Pa/h |
0.65Pa/h |
0.65Pa/h |
0.67Pa/h |
0.67Pa/h |
0.68Pa/h |
0.68Pa/h |
Note:
We can design and produce according to the users' specific requirements of technical parameters.
Application:
1.Vacuum Gas Quenching: tool steel, alloy steel, stainless steel, copper alloy etc.
1.Vacuum Brazing: brazing of nickel, copper and silver based material
Spare Parts:
Rapid fuse PCS 1
Pipe Seal SETS 1
Vacuum Grease PCS 1
Insulating Ceramic SETS 1
Heater SETS 1
Vacuum Seal SETS 1
Pirani Gauge PCS 2
Thermocouple PCS 1
