semiauto blow molding machine

Name: semiauto blow molding machine
Brand: Eceng
Price: USD $2,000 - 3,600 / Set

FOB Price

USD $2,000 - $3,600 / Set

1 Set(Min.Order)

Product Details

Condition:	New	Application:	Bottle	Plastic Processed:	Other, PP PE PET
Blow Moulding Type:	Stretch Blow Moulding	Automatic:	Other, semiautomatic	Place of Origin:	Jiangsu, China
Brand Name:	Eceng	Model Number:	YC-2L-2	Voltage:	220V
Power(W):	20KW	Dimension(LWH):	1.460.581.8M	Weight:	1000KG
Certification:	CE	Warranty:	one year	After-sales Service Provided:	No overseas service provided

semiauto blow molding machine

Main machine (blower + oven)	Model type	Tech data
Product Spec	Max. product volume(L/cav)	2
	Max. preform neck size(mm)	100
	Max. product diameter(mm)	180
	Max. product height (mm)	300
	Cavities	2
Blow molding part	Die force (KN)	100
	Die stroke (mm)	270
	Max. mould size(mm)	390*345
	Mould thickness	Adjustable
	Mould spacing(mm)	400
	Max. pulling stroke(mm)	400
	Operation pressure(Mpa)	0.8-1.0
	Operation air pressure consumption (1tr/min)	200
	Blow pressure(Mpa)	1.2-2.8
	Blow air pressure consumption (1tr/min)	300
	Output(pcs/h)	800-1000(500ml bottle)
	Machine size(LxWxH)(m)	1.460.581.8
	Machine weight(KG)	650
Oven	Temperature grade(rate)	8
	Heating time(S)	90-200
	Voltage(V)	220 or as your request
	Frequency(HZ)	50/60
	Total power(KW)	16
	Oven Size (LxWxH)	1.350.551.15
	Oven weight (KG)	300

Auxiliary device	Required Spec	YC-2L-2
High pressure air compressor	Operation air pressure	3.0 Mpa
	Air displacement	0.75 m3/min
	Power	9 Kw
	R.P.M	800
	Weight	460 Kg
	Dimension	1.86m0.9m1.4m
Air filter (oil-water separator )	Filter precision	≤5ppm
	Weight	28Kg
	Dimension	0.24m0.26m0.73m

Zhangjiagang Eceng Machinery Co., Ltd.: Contact nameRiverman Zhang; Phone86-512-56985363; AddressRm. 1207, Bldg. 1, Dongfang Xintiandi
