Home > Electrical & Electronics > Antenna > Communication Antenna > Mini GPS Antenna AVIC Connector

Mini GPS Antenna AVIC Connector

Name: Mini GPS Antenna AVIC Connector
Brand: superbat
SKU: 121476465

Mini GPS Antenna AVIC Connector thumbnail-1

US$ 6.5 - 7.9 MOQ: 10 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

superbat

Model Number:

GA07-300-A01SJ

Contact Supplier Request Quote Chat Now

Shenzhen Superbat Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name superbat

Model Number GA07-300-A01SJ

Specifications

1.Mini GPS antenna AVIC connector RG174 3 m
2.Compatibility:Pioneer AVIC-D1
3.Dependable performance
4.GA07-300-A01SJ

Mini GPS antenna AVIC connector for Pioneer AVIC-D1 AVIC-D2 AVIC-D3 AVIC-N5

Characteristic:

(i) Dieletric Antenna
Center Frequency 1575.42MHz±3 MHz
V.S.W.R 1.5:1
Band Width ±5 MHz
Impendence 50 ohm
Peak Gain >3dBic Based on 7×7cm ground plane
Gain Coverage >-4dBic at –90°<0<+90°(over 75% Volume)
Polarization RHCP

(ii) LNA/Filter
LNA Gain (Without cable) 28+/-3dB
Noise Figure 1.5dB Typ.
Filter Out Band Attenuation (f° =1575.42MHz)
7dB Min f0+/-20MHZ ;
20dB Min f0+/-50MHZ;
30dB Min f0+/-100MHZ
V.S.W.R <2.0
DC Voltage 2.7V/3.0V/3.3V/5.0V/3.0V to 5.0V/other
DC Current 5mA /11mA/15mA Max

(iii)Mechanical
Weight <100gram
Size 49x39x15mm
Cable :RG174 3 meter / contact us for other length
Connector :SMA/SMB/SMC/BNC/FME/TNC/MCX /MMCX /Fakra/AVIC/WILIC in straight or right angle please give us some notes if you need to change the antenna connector .Tks!
Mounting Magnetic base
Housing Black

(iv)Environmental
Working Temp -40°C~+85°C
Storage Temp. -45°C~+100°C
Vibration Sine sweep 1g(0-p)10~50~10Hz each axis
Relative Humidity 95% non-condensing
Weatherproof 100% Waterproof

(V) FEATURES:

Compact Construction/ Low Profile/
Fully Waterproof
Magnet and Screw Mount Base
Excellent Temperature Stability
Low Noise Figure
High Sensitivity

(VI) APPLICATIONS:

Automobile GPS
Bluetooth Receiver
Car Tracking Navigation System
AVL / Fleet Management Systems
External Antenna for Handheld GPS
External Antenna for PDA Navigator

Mini-GPS antenna with AVIC compatibility:

PIONEER AVIC Serie (AVIC-X1, X1R, 991HVT, 810HVT, 710T, 610T, 800DVD-50, 900)
PIONEER N1, N2, N3 Serie

AVIC D1 D2 D3 Z1 Z2 N1 N2 N3 N4 N5
AVIC 90DVD 80DVD 9DVD 8DVDco

Payment
We accept T/T, Western Union, Escrow and Paypal.

Shipping
1. The parts from us are sure to have quality warranty,and they are double tested before shipping.
2. The items can be sent within 2 working day after the payment reaches us,except for mass process, we will confirm the delivery in advance.
3. We can send your order by UPS/DHL/TNT/EMS/FedEx. Pls contact us directly and we will use your preferred ways.
4. Any import fees or charges are the buyer's responsibility. But we can help you reduce and avoid import taxes by declaring prices low, declaring the contents as "electronic accessories" or other items and shipping in simple packaging.
5. Sample is available.

Warranty
1. We can guarantee the product quality within 1 year.
2. If products cannot work,refund or exchange is available.
We provide comprehensive after-sales service, including quality service, guidance services,We focus on customer needs in every detail.Please contact us if you need our detail warranty term.

About us
We specialises in the sale of RF coaxial connectors,adapters, cable assemblies,3G/GSM/WIFI/GPS antennas etc, and especially provides custom services for these products. we own the "Xtar" and "superbat" trademark.
We own a mature and professional Sales Team and Technical Team,and set up a good and long-term relationship with over 50 domestic manufactures of coaxial connector and antenna.We have served for over 86000 customers from more than 120 countries on ebay, alibaba and our online shop.We have achieved great admiration and we are widely trusted at home and abroad.

Our mission is: Provide an Internet-based integrated supply chain for small and medium-sized users and retailers of RF and microwave components in the world.
