Cutting Plotter (LIYU SC-L Series)

Name: Cutting Plotter (LIYU SC-L Series)
Brand: LIYU
SKU: 121387307
Availability: InStock

Negotiable MOQ: 10 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Anhui, China

Brand Name:

LIYU

Model Number:

SC631/801/1261-L

Anhui Liyu Computer Equipment Manu. Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Anhui, China

Brand Name LIYU

Model Number SC631/801/1261-L

Voltage AC220V/110V,50Hz~60Hz

Cache Capacity 1Mb

Paper Feed Width 710/880/1340mm

Cutter Pressure 10~400g

Cutting Width 400mm/630mm/800mm/1.2m

Cutting Speed 400mm/s

Driver Direct Output from CorelDraw

Specifications

High quality Aluminum stand, LCD, durable and Steady, USB 2.0 interface, Most poplular and classsic model, 14 months Warranty!

Technical Specifications for SC-L series cutting plotter:

1. High quality Aluminum stands, more durable and Steady, high-grade.

2. Serial port, USB 2.0 optional, support hot-swappable.

3. Inertial rotating blade holder enables more accurate and high quality cutting.

4. Digital force & speed adjustable, direct and steady.

5. Auto. memory of blade force & Speed, adjustable at any time, easy to use.

6. Emergency stops & stops to return at any time to monitor the cutting quality, easy to operate.

7. Bulk copy up to 99, saving time and strength.

8. Unique red cutting slot, elegant, easy to operate.

MODEL	SC400	SC631-L	SC801-L	SC1061-L	SC1261-L
Drive Motor	Sepecial Stepper Motor
Media Size	470mm/1.54ft	710mm/2.33ft	880mm/2.89ft	1120mm/3.67ft	1340mm/4.40ft
Cutting Size	390mm/1.28ft	630mm/2.07ft	800mm/2.62ft	1040mm/3.41ft	1260mm/4.13ft
Max.Cutting Speed	400mm/s
Cutting Force	10~400g
LCD	With
Buffer capacity	1Mb
Resolution	0.025mm/step(0.001in./step)
Repeatability	0.127mm/0.005in.
Commands Set	HPGL or DMPL
Interfaces	Serial, USB optional
Positioning Mode	Origin Setup atrandom available
Copy Function	Up to 99 copies
Power	<100W
Power requirementst	AC220V/110V,50Hz~60Hz
Windows Driver	Direct Output from CorelDraw
Packing Size (WXDXH)	0.8X0.36X0.4m (0.62X1.18X1.31ft)	1.04X0.36X0.4m (3.41X1.18X1.31ft)	1.19X0.36X0.4m (3.90X1.18X1.31ft)	1.43X0.36X0.4m (4.69X1.18X1.31ft)	1.64X0.36X0.4m (5.38X1.18X1.31ft)
G./Weight	14KG/31lbs	20KG/45lbs	25KG/55lbs	32KG/70.4lbs	39.0KG/86lbs
Environment	Temperature:035, 5%-95%Non-condensing
