CC2530 (2.4GHz) Low Power Long Range Sensor Module
(P/N: CC2530PA)
CC2530 2.4GHz Wireless Module
General Description
The CC2530PARF Module is a low-power, embedded long range Power Amplifier (PA) highly integrated 2.4-GHz transceiver that suitable for systems targeting compliance with worldwide radio-frequency. It’s a true system-on-chip solution for 2.4-GHz IEEE802.15.4,Wireless applications.
Electrical Characteristics
Ta = 25°C, VCC = 3.3V
Typically, equipment utilizing this device requires emissions testing and government
approval, which is the responsibility of the equipment manufacture.
ITEM |
PARAMETER |
UNIT |
||
MIN |
TYPICAL |
MAX |
||
|
Voltage supply
|
3.0 |
3.3 |
3.6 |
V |
Transmitting current |
36 |
38 |
40 |
mA |
Receiving current |
25 |
26 |
27 |
mA |
Sleep consumption |
|
1 |
|
uA |
frequency |
2.405 |
|
2.485 |
GHz |
Output power |
3.8 |
4.0 |
4.2 |
dBm |
Receiving sensitivity |
|
-97 |
|
dBm |
Data rate |
|
250 |
|
Kbps |
Transmit distance |
|
100 |
|
m |
Baud Rate |
2400 |
9600 |
115200 |
bps |
Operating temperature |
-40 |
|
80 |
°C |
Package size |
28×20×2 mm |
|||
Radio
·2.4-GHz IEEE802.15.4 compliant RF transceiver
·Excellent receiver sensitivity and robustness toInterference, receiver sensitivity reach to -97dBm
·Programmable output power up to 4.5dBm
·Suitable for systems targeting compliance with worldwide radio-frequency
·Accurate digital RSSI/LQI support
·data rate: 250kBank
8051 MCU
·Powerful five-channel DMA
·128KB in-system programmable flash, customization 32-,64-,256KB
·8KB RAM with retention in all power modes
·CSMA/CA hardware support
·AES security coprocessor
·Battery monitor and temperature sensor
·12-Bit ADC with eight channels and configurable resolution
·Two powerful USARTs with support for several serial protocols
·IEEE 802.15.4 MAC timer, general-purpose timers (One 16-Bit, Two 8-Bit)
·32-kHz sleep timer with capture
·Watchdog timer
·21 general-purpose I/O pins (19× 4 mA, 2×20 mA)
·Hardware debug support
-CC2530-Z1 RF Module
·Applications
·2.4-GHz IEEE 802.15.4 systems
·Wirless systems (256-KB flash)
·Home/Building automation
·Lighting systems
·Industrial control and monitoring
·Low-Power wireless sensor networks
·Consumer electronics
·Health care
-RFID Real-Time Applications
