Help CenterComifo Ductwork Forming Machine IV
Related Products
Specifications
1.Ductwork forming machine2.Stable and reliable performance
3.PLC control, touchscreen
4.Mitsubishi servo motor
Comifo Duct Manufacture Auto Line IV also called ductwork forming machine, coil line,rectangle duct line
Features:
>Modular design allows adding a section at a time, can be upgraded to Auto Line V or Auto Line VII
>Two sets of twin-motor driven dual-decoilings, selectable coils stand by, maximum capacity of 5-ton per station (optional: up to 10-ton per station)
>Straightening/flattening - Pneumatic controlled straightener
>Pneumatic controlled ring type beading rolls with five beading rings-which can be removed
>Patented Automotion pittsburgh lock former, forms pittsburgh lock and right angle, roll forming and shearing simultaneously, shorten working time, a perfect match to duct auto line
>Optimizes floor space by inline position of machines, guarantees high efficiency
>Accurate PLC control unit, preset available profiles and folding style, notching size, punching size, cutting dimension on touchscreen
Stations: coil-straightening-beading-punching square-notching-shearing-folding-automotion pittsburgh lock forming
Model No. |
Max Coil Width |
Thickness Range |
Speed |
Shearing Tolerance |
Diagonal Tolerance |
CAL4-1.2x1300 |
1300mm
|
0.4-1.2mm 18-30ga
|
0-18m/min 0-59FPM |
±0.5mm |
±0.5mm |
CAL4-1.2x1600 |
1600mm
|
Work Flow:
More Detailed Pictures:
