Home > Manufacturing & Processing Machinery > Machine Tools > CNC Machine Tools > 3-axies Hard Rail CNC Vertical Machining Center
3-axies Hard Rail CNC Vertical Machining Center
US$ 39,500 - 41,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Vertical
Place of Origin:
China
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Precision Auto Turning Center HL-25NNegotiableMOQ: 1 Set -
5-Axes Line Rail CNC Vertical Milling Machine for Making Car Wheels LV-1260US$ 37,500 - 72,000MOQ: 1 Set
-
5-Axes Line Rail CNC Vertical Milling Machine for Consumer Electronics Parts Processing LV-1260US$ 37,500 - 72,000MOQ: 1 Set
-
LV-1260 5-Axes Line Rail CNC Vertical Machine Center for Making Automobile PartsUS$ 37,500 - 72,000MOQ: 1 Set
-
LV-850 Three Axes Heavy Roller Line Rail CNC Milling MachineNegotiableMOQ: 1 Set
Condition
New
Type
Vertical
Place of Origin
China
Brand Name
HHT
Model Number
VMC-650,VMC-850
Voltage
380V or as required
Weight
4500,4800kg
Certification
ISO,CE
Warranty
1 year
After-sales Service Provided
Engineers available to service machinery overseas
Product Description
| Item Model | Unit | VMC-650 | VMC-850 |
| working tale size | mm | 420x800 | 500X1000 |
| X/Y/Z travel | mm | 650/400/480 | 800/500/600 |
|
Distance between spindle end and table |
mm | 80-560 | 110-700 |
|
Distance between spindle center and column guide way |
mm | 480 | 560 |
| Maximum weight of working table | kg | 600 | 600 |
| table-T-slot | mm | 3-18-135 | 3-18-150 |
| X/Y/Z axis rapid feed | mm/min | 18000 | 18000 |
| three axis working rapid speed | mm/min | 8000 | 8000 |
| X.Y.Z axis screw mandrel size | mm | 3206 | 4010 |
| positioning accuracy | mm | ±0.005/300 | ±0.005/300 |
| repeat positioning accuracy | mm | ±0.003 | ±0.003 |
| spindle speed | rpm | 8000 | 8000 |
| spindle taper | mm | BT40/150 | BT40/150 |
| control system | / | MITSUBISHI-M70VA | |
| torque force of spindle motor | nm/kw | 35/7.5 | 35/7.5 |
| torque force of X.Y.Z motor | nm | 13.7-47 | 20-50 |
| pneumatic source requirement | Kg/Cm2 | 6 | 6 |
| power consumption | kva | 18 | 20 |
| machine size | mm | 2300*2000*2500 | 2550*2200*2700 |
| machine weight | kg | 4500 | 4800 |
The Reasons for Choosing us:
1.Excellent after-sale-service
a. Free installation and debugging
b. Free operator training
c. Free maintenance within 1 year
d. Long warranty and technology support
2. High quality
The main parts of our machines are imported from Japan, Germany and USA. Some are made in Taiwan.
You are welcomed to visit our factory.
3. Low Price
We make sure that for same price, our quality is much more excellent.
If you meed more detailed information,please feel free to contact me as following:
Yangyang.Niu
Trademanager: cn1513256925
Skype: Yangyang.Niu
