High tech hf vacuum drying equipment for drying plank/lumber/merbau
About the Henan dingli drying equipment co.,ltd
1.We are Henan Dingli Drying Equipment Co.,Ltd, locate at No.59,Dongda Street, Guancheng Dist., Zhengzhou, China. we are professional manufacturer in new energy and biomass fuel ewuipment and have been 20 years experience.
2.our main equipment is drying machine, which devided into rotary dryer and HF wood vacuum dryer machine.
3.we are able to design suitable for your machine with your demands! welcome to visit our factory!
4.If you want to know more about hf vacuum dryer kilns, you can visit our website: htpp:///
GZ-6.0III-DL vacuum drying equipment, HF drier,rotary vacuum dryer type:
HF vacuum dryer is a kind of drying machine with low temperature in vacuum situation, smaller but much faster than the conventional kilns.
Model |
GZ-6.0III-DL |
Capacity |
6.6 CBM |
Out Dimension (mm) |
L6500xW1916xH2006 |
Inside dimension (mm) |
L5700xW1700xH1700 |
Timber cart (mm) |
L5000xW1200xH1000 |
Max Length of Wood |
5m |
High Frequency |
6.78MHz |
Input Power |
30KVA |
Oscillation power |
20KW |
Vacuum pressure |
-0.093MPa |
Weight(kg) |
7000 |
Packing |
40HQ |
Kiln Temp |
Vacuum kiln Drying temperature: ≤90°C |
Moisture |
From 90% to 6% ,could be setting as per-request |
Drying time |
2-7 days |
Application |
Apply for all hardwood species |
hf vacuum drying equipment pictures display in our warehouse
Charactor of hf vacuum drying equipment
A.OFFER ONE BUTTON CONTROL TECHNOLOGY
Full automatic drying program within PLC control system for different type of wood, the worker don’t need to know too much knowledge about wood drying cook th wood perfect.
B.PRECISE AND RELIABLE MONITORING SYSTEM
High precision and stable monitoring spare will always guide on the machine both for warrantee of good drying quality or safety of personal and machine.
C.WELL SELECT SPARE PARTS
We choose high grade stable spare parts which is tested for long time for the machine to make it stable running and problem free.
D.LOGICAL AND SAFE DESIGN
With more than 200 years of experienced engineer, the customer can expect a more logical and humanistic machine that very easy to use, stable running and help a lot in production.
Our advantages
1.We are professional manufacturer and have more than 20 years experience as well as engaged in hf vacuum dryer kilns.
2.we are responsible for users’ site planning, process design, equipment installation and operation training. And our engineer is available to go overseas install hf vacuum dryer kilns for you
3.warranty:one year for hf vacuum dryer kilns,and long-term supply of parts
The mentioned above just our High tech hf vacuum drying equipment for drying plank/lumber/merbau, if you want to know more details, welcome to contact me!
