Help CenterEngineering Plastic Pellet Drying Line Nylon PC ABS PET Plastic Raw Material Drying Equipment
Product Spotlights
Related Products
-
Continuous Plastic Granule Drying Machine Plastic Raw Material Pre-drying Production LineNegotiableMOQ: 1 Set -
Plastic Product Drying Line for PET/PP Recycling Pellets, Hot Air Circulation SystemNegotiableMOQ: 1 Set
-
Energy-Saving Plastic Product Drying Line With Frequency Inverter and Overheat Protection, PLCNegotiableMOQ: 1 Set
-
High Efficiency Plastic Resin Drying Line Engineering Plastic Pellet Dehydration EquipmentNegotiableMOQ: 1 Set
-
Industrial Dryer for Plastic Resin Before Molding ProcessingNegotiableMOQ: 1 Set
Deqing Leixin Coating Equipment Co., Ltd., a professional manufacturer established in 2011 in Huzhou, Zhejiang, China, is proud to present our Engineering Plastic Pellet Drying Line designed specifically for Nylon, PC, ABS, PET, and other plastic raw materials. Our factory, spanning 1,000-3,000 square meters with a team of 51-100 skilled employees, has accumulated over a decade of expertise in drying equipment. This drying line delivers consistent, low-moisture outputs essential for high-quality injection molding and extrusion processes. With annual exports exceeding US$1 million to global markets including North America, Europe, Southeast Asia, and Oceania, our solution is trusted by international buyers for its reliability and efficiency.
Key technical highlights of this plastic pellet drying line include:
- Multi-material compatibility: Handles hygroscopic engineering plastics such as Nylon (PA), PC, ABS, PET, POM, and more with customized temperature profiles.
- Precise dehumidification: Utilizes hot-air drying or optional dehumidifying dryers to achieve moisture content as low as 0.02% (depending on material and model).
- Energy-efficient design: Insulated drying hoppers and optimized airflow reduce heat loss and power consumption by up to 20% compared to conventional dryers.
- PLC touch-screen control: Intuitive interface for setting parameters, monitoring real-time data, and storing up to 100 recipes (available as optional upgrade).
- Sturdy construction: Main frame made of stainless steel or carbon steel with anti-corrosion coating, ensuring long service life in industrial environments.
- Customizable capacity: Standard models from 100 kg/h to 2000 kg/h; larger capacities available upon request.
- Safety integrated: Over-temperature protection, emergency stop, and alarm system to safeguard operators and materials.
Below are typical technical specifications for reference (exact parameters depend on model):
| Parameter | Value Range | Notes |
|---|---|---|
| Drying Temperature | 65°C - 180°C | Adjustable via controller |
| Hopper Volume | 0.5 - 10 m³ | Customizable |
| Heating Power | 15 - 80 kW | Depending on capacity |
| Air Flow Rate | 500 - 5000 m³/h | Adjustable |
| Material Inlet/Outlet | DN150 - DN300 | Standard flanged connections |
| Power Supply | 380V/50Hz (or as required) | 3-phase, customizable |
This drying line brings clear benefits to your production:
- Higher product quality: Uniform drying prevents splay marks, brittleness, and dimensional instability in final parts.
- Reduced scrap rate: Consistent moisture removal minimizes defective products, saving material and cost.
- Faster processing cycles: Pre-dried pellets allow higher injection speeds and lower mold temperatures, increasing overall throughput.
- Flexibility for different materials: Quick changeover between nylon, PC, ABS, and PET without cross-contamination (optional dedicated hopper available).
- Low maintenance: Modular design and durable components (e.g., Siemens or equivalent motors) minimize downtime.
Backed by our ISO9001 certified quality management system, Deqing Leixin Coating Equipment Co., Ltd. ensures strict quality control from raw material procurement to final assembly. Our team of 51-100 experienced workers and engineers has delivered equipment to clients across North America, South America, Europe, Africa, Oceania, and Asia. With annual exports of US$1 million – US$1.5 million, we have built long-term partnerships with plastic processors worldwide. Every drying line undergoes full functional testing before shipment. We also provide technical documentation, installation guidance, and after-sales support to ensure smooth commissioning at your facility. Choose our Engineering Plastic Pellet Drying Line to optimize your drying process and boost your production efficiency. Contact us today for a customized solution tailored to your material and capacity needs.
Frequently Asked Questions
Q1: Can this drying line handle Nylon 6 and Nylon 66?
A: Yes. The system is designed for a wide range of engineering plastics including Nylon 6, Nylon 66, PA12, etc. Temperature can be precisely controlled to avoid degradation. Please specify your material when ordering for optimal calibration.
Q2: What is the typical drying time for PC and ABS?
A: For PC, typical drying time is 2-4 hours at 120-130°C; for ABS, it is 2-3 hours at 80-100°C. Actual time depends on initial moisture content and ambient humidity. Our machine includes a timer and alarm to alert when drying is complete.
Q3: Do you offer a dehumidifying dryer option instead of hot air?
A: Yes, we provide an optional dehumidifying (low-pressure) dryer with a molecular sieve desiccant bed for materials requiring very low dew point, such as PET and Nylon. This can be integrated into the same line.
Q4: What is the power consumption for a 500 kg/h model?
A: Approximately 30-40 kW for heating and blower, depending on temperature and ambient conditions. Actual consumption can be verified with our sales team based on your specific requirements.
Q5: How do you ensure uniform drying of pellets?
A: Our hopper design incorporates a conical shape with a central air distribution system that ensures even airflow through the entire pellet bed. Additionally, the PLC controller adjusts inlet temperature to maintain stable conditions.
Q6: Can the machine be customized for explosion-proof environments?
A: Yes, we can equip the drying line with explosion-proof motors, electrical components, and ATEX-certified sensors if required. Please contact us with your safety standards during inquiry.
Q7: What is the warranty period?
A: Standard warranty is 12 months from the date of shipment or 18 months from installation, whichever comes first. Extended warranty plans are available upon negotiation.
Q8: Do you provide installation supervision?
A: Yes. We offer on-site installation and commissioning service at an additional cost, or remote guidance via video call for simple setups. Detailed manuals and drawings are also provided.
