Outline
Six-speed rotational viscometer can be measured for each rheological parameters, drawn in accordance with multi-point measurement value flow curve to determine the flow of the liquid in the course of the flow pattern, choose the appropriate formula for non-Newtonian fluids for a more accurate measurement, Research on rheological parameters of drilling fluids for field analysis, at the same time, can be dynamic and static shear measurement, flow index and consistency coefficient and a series of technical parameters. Conducive to safe, fast, scientific drilling needs. Easy to operate, test accurate.
Second, the model and specifications
ZNN-D6 measuring type F1 torsion spring assembly
F0.2 torsion spring measurement unit (optional)
Third, the main technical parameters of the instrument
The main technical parameters
| NO | NAME | Technical Indicators |
| 1 | power supply | 220V±5% 50Hz |
| 2 | .Motor Power | 7.5W/15W |
| 3 | Motor speed | 750/1500 r/min |
| 4 | Speed range | 3,6,100,200,300,600r/min |
| 5 | Speed ladder | 5,10,170,340,511,1022 S-1 |
| 6 | measurement accuracy | 1 ~ 25 mPa • s ± 1 mPa.s (Newtonian fluid) 25 mPa • s more than ± 4% (Newtonian fluid) |
| 7 | Viscosity measurement range | Newtonian fluid: 1 ~ 300mPa.s (F1 measurement unit) 1 ~ 60mPa.s (F0.2 measurement unit) Non-Newtonian Fluid: 1 ~ 150 mPa.s (F1 measurement unit) 1 ~ 30 mPa.s (F0.2 measurement unit) Shear stress: 0 ~ 153.3Pa (F1 measurement unit) 0 ~ 30.7Pa (F0.2 measurement unit) |
Qingdao Best Investor Petroleum Machinery Manufacturing Co., Ltd. is a viscometer, filtration device, roller furnace, high-speed mixer, Viscosity detector and other professional production and processing company, has a complete and scientific quality management system. Integrity, strength and quality of products Qingdao Best Investor Petroleum Machinery Manufacturing Co., Ltd. is recognized by the industry. Welcome friends to visit, guidance and business negotiation
Qingdao Best Investor Petroleum Machinery Manufacturing Co., Ltd., founded in 2006, specializes in manufacturing series of oil slurry analytical instruments and accessories, which are widely used in major scientific research, oil drilling, oil and chemical additives in colleges.
I produced the high-quality products to meet domestic demand basis exported to many countries of the Sudan, Saudi Arabia, Iran, India and Uzbekistan.
Companies with a sound quality management system, and in accordance with API standard development and production of drilling fluids, completion fluids testing equipment.
Qingdao Best Investor Petroleum Machinery Manufacturing Co., Ltd. is a viscometer, filtration device, roller furnace, high-speed mixer, Viscosity detector and other professional production and processing company, has a complete and scientific quality management system. Integrity, strength and quality of products Qingdao Best Investor Petroleum Machinery Manufacturing Co., Ltd. is recognized by the industry. Welcome friends to visit, guidance and business negotiation
