High Accuracy Total Station With GPS Navigation for Geological Survey

High Accuracy Total Station With GPS Navigation for Geological Survey thumbnail-1
High Accuracy Total Station With GPS Navigation for Geological Survey photo-1
US$ 0.1 - 0.2 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Chongqing, China
Brand Name:
Hi-Target Total Station GPS
Model Number:
ZTS-320R Total Station
Contact Supplier Request Quote Chat Now
Chongqing Huobo Surveying Instruments Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing Qingdao Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Chongqing, China
Brand Name Hi-Target Total Station GPS
Model Number ZTS-320R Total Station



 Hi-Target ZTS-320R Total Station Surveying Instrument:

This kind of Hi-Target high precision new total station is widely used in surveying and mapping,engineering construction,it's popular in the market for it's high precision,good quality,competitive price...,It can help customers to do most of the work in surveying and mapping.

As for Hi-Target brand Engineering Construction New Condition Total Station,it's a yonger products,full of creative and thoughtful sonsideration.It's really a competitive prodcts compete with other brand.

Product Description

*Technical Data of Our Total Station GPS Geological Survey:

Angle Measurement

Measurement Method: Absolute Encoding

Minimum Readout: 1″/5″/10″(0.3mgon/1.5mgon/3mgon) adjustable

Accuracy1: 2”



Distance Measurement (ZTS-320 with Reflector)

Single Prism: 3000m (9,842ft.) under good condition3

Three Prisms: 6000m (19,685ft.) under good condition3

Reflective Sheet: 800m (2,624 ft.)

Accuracy: 2 mm+2ppm

Measuring Time (Fine/Quick/Tracking): 1.5s/1s/ 0.5s



Distance Measurement(ZTS-320R Reflectorless)

Reflectorless2 Range: 350m(1,148 ft.)

Single Prism: >7500m(24,606ft.)

Accuracy: 3mm+2ppm

Measuring Time: 1.5s



Telescope

Magnification: 30X

Field of View: 1°30′ (2.7m at 100m)

Minimum Focusing Distance:1.5m

Reticle: Illuminated



Compensator

System: Single-axis liquid tilt sensor/Dual-axis (optional)

Working Range: ±3′

Setting Accuracy: 1″



Communication

Bluetooth

Interface:Standard RS232,SD card4,USB pen drive,mini-B

Internal Data Memory:Approx.20,000 Points

Data Format:ASCII



Operation

Operation system: Real-time Operating System

Display:High resolution backlight black and white display with contrast adjustment/ Graphics: 192 x 96 pixels

Character:6 lines x 25 characters

Keyboard:2 sides Alphanumeric backlit crystal keyboard



Laser Plummet

Type:Laser point, 4 brightness levels adjustment / Optical plummet (optional)

Centering Accuracy:1 mm at 1.5m instrument height



Power Supply

Battery Type:Rechargeable Li-ion battery

Voltage/Capacity:ZBA-400: 7.4V (DC) / 3000mAh

Operating Time With ZBA-400:Optimal 16 hours5 (Continuous angle measurement every 30 seconds)/10 hours (typical)

Measuring Times:Approx. 12000 times



Weight

Weight (Incl. Battery & Tribrach): Approx. 5.5kg (12.1lb.)



Environmental

Operating Temperature: -20℃ ~+50℃( -4℉ to + 122℉)

Storage Temperature: -40℃ ~+70℃(-40℉to + 158℉)

Dust &Water Proof (IEC60529 Standard)/Humidity: IP65, 95%, non-condensing)



*Advantages of Our Total Station Surveying Instrument:

1.High precision;

2.Competitive quality and price;

3.Strong Technical support;

4.1 year warrenty;

5.Thoughtful after-sales service.

Packaging & Shipping

*Packaging:

The total station is packaged with plastic box inside and carton box outside,1PC/Carton.

*Delivery:

We usually arrange delivery within 7 working days.

Company Information

 *Short Introduction of Our Company:

Chongqing Gold Mechanical & Electrical Equipment Co.,Ltd is a high-tech enterprise for researching,designing,developing and producing oil treatment equipment.With it’s continuous drawing of lessons,unremitting innovation and borrowing of advanced technology from both at home and abroad,our company is now becoming a professional manufacturer of surveying and mapping equipments,such as GPS,Total Station,Drilling rigs and so on. All of our products are excellent in quality.Though highly acclaimed and favorably accepted by numerous customers and possessed of the right to import and export,to insure the high quality of our products,we conduct our manufacturing in strict axxordance with the highest srandard we can do.

We have persisted on the business idea of “Integrity Basis and Quality First” for the stable and constant development.We are making effort to develop together with customers from both domestic and abroad on the basis of reciprocity.Client,quality and service are our supreme target.
