Data Link Fast Survey GNSS System Dual Frequency V30 GPS RTK
It is designed to meet high quality standards at an affordable price. It is outstanding in its
class, with a rugged design and user-friendly functions.
V30 GPS is equipped with a smart speaker guiding the whole operation.Multi one-button functions make fieldwork easier,such as auto base setup by one button,The rover can get fix solution once it is turned on.
Seamless operation in CORS system,Built-in GPRS/GSM/3G module ensures that the V30 works perfectly with network RTK positioning. IP67 dust/water protection. Withstands 3-meter natural fall onto concrete.
Rapid tracking and perfect avoidance or reduction of obstruction and multipath effect to ensure superior positioning capability.
Independence: No external cable or battery is needed, so you can put it where you want.
Compatibility: It can both directly transmit and forward in same-frequency or pilot-frequency
Multi-channel: It has 116 UHF channels, and supports custom channels.
Power: 5W / 10W / 20W / 35W adjustable
Distance: Its max working distance is 50 km, which depends on the setting altitude.
Resistant features: waterproof, dustproof, broken-resistant performance.
Intelligentialized self-diagnosis function
| Model | GPS V30 |
| Measurements | |
| 220 tracking channels | |
| Advanced Pacific Crest Maxwell 6 Custom Survey GNSS Technology | |
| High precision multiple correlator for GNSS pseudo range measurements | |
| Unfiltered, unsmoothed pseudo range measurements data for low noise, low multipath error, low time domain correlation and high dynamic response | |
| Very low noise GNSS carrier phase measurements with <1 mm precision in a 1 Hz bandwidth | |
| Signal-to-Noise ratios reported in dB-Hz | |
| Proven Pacific Crest low elevation tracking technology | |
| Satellite signals tracked simultaneously | |
| GPS | Simultaneous L1C/A, L2C, L2E, L5 |
| GLONASS | Simultaneous L1C/A, L1P, L2C/A (GLONASS M only), L2P |
| SBAS | Simultaneous L1 C/A, L5 |
| Galileo | Simultaneous L1 BOC, E5A, E5B, E5AltBOC |
| BDS | B1, B2 |
| QZSS | L1 C/A, L1 SAIF, L2C, L5 |
| POSITIONING PERFORMANCE | |
| Static and Fast Static GNSS surveying | |
| Horizontal | 2.5mm+0.5ppm RMS |
| Vertical | 5mm+0.5ppm RMS |
| Post Processing Kinematic | |
| (PPK / Stop & Go) GNSS surveying | |
| Horizontal | 1cm+1ppm RMS |
| Vertical | 2.5cm+1ppm RMS |
| Initialization time | typically 10 minutes for base while 5 minutes for rover |
| Initialization reliability | typically > 99.9% |
| RealtimeKinematic(RTK) surveying | |
| Horizontal | 8mm+1ppm RMS |
| Vertical | 15mm+1ppm RMS |
| Initialization time | typically < 8 seconds |
| Initialization reliability | typically > 99.9% |
| Code Differential GNSS positioning | |
| Horizontal | 25cm+1ppm RMS |
| Vertical | 50cm+1ppm RMS |
| SBAS | 0.50m Horizontal, 0.85m Vertical |
| HARDWARE | |
| Physical | |
| Dimensions (W x H) | 19.50cm x 10.40cm(7.68 in x 4.09 in) |
| Weight | 1.3kg (2.86lb) with internal battery, internal radio, standard UHF antenna |
| Operating temperature | below 45℃ to above 65℃ (-49℉ to +149℉) |
| Storage temperature | below 55℃ to above 85℃ (-67℉ to +185℉) |
| Humidity | 100%, considering |
| Water/dustproof | IP67 dustproof, protected from temporary immersion to depth of 1m (3.28ft). |
| Shock and Vibration | Designed to survive a 3m(9.84ft) natural fall onto concrete |
| Electrical | |
| Power 6V to 28V DC external power input | |
| Power consumption 2.5W | |
| Automatic Switching between internal power and external power | |
| Rechargeable, removable 7.4V, 5000mAh Lithium-Ion battery in internal battery compartment | |
| Internal battery life | |
| Static 13 - 15 hours | |
| RTK Rover (UHF/GPRS/3G) 10 - 12 hours | |
| RTK Base 8 - 10 hours | |
| I/O interface | |
| 1 x Bluetooth | |
| 1 x standard USB2.0 port | |
| 2 x RS232 serial port | |
| 2 x DC power input (8-pin & 5-pin) | |
| COMMUNICATION AND DATA STORAGE | |
| GPRS/GSM or 3G | |
| Fully integrated, fully sealed internal GPRS/GSM or 3G | |
| Network RTK (via CORS) range20-50km | |
| HI-TARGET internal UHF radio (standard) | |
| Frequency | |
| Transmitting Power | 0.1W, 1W, 2W adjustable |
| Transmitting Speed | Up to 19.2Kbps |
| Working Range | 3~5Km typical, 8~10km optimal |
| Pacific Crest XDL micro Internal UHF Radio | |
| Frequency | 403~473 MHz |
| Transmitting Power | Up to 19.2Kbps |
| Working Range | 3~5km typical, 8~10km optimal |
| Support most of radio communication protocol | |
| HI-TARGET External UHF radio (standard) | |
| Frequency | 460 MHz with 116 channels |
| Transmitting Power | 5W, 10W, 20W, 30W adjustable |
| Transmitting Speed | Up to 19.2Kbps |
| Working Range | 8~10Km typical, 15~20km optimal |
Activities display
1.We have more than 6 years of developed sales chanels in many countries.
2.Our company are highly acclaimed and favorably accepted by numerous customers and possessed of the right to import and export.
3.We prominent emphasize the human concern,respect,rust in company management,as we as stimulate staff's sense of responsibility and the sense of mission.
4.Inspected by the Inspection Institution of Bureau Veritas Certification.
5.100% QC inspection Before Shippment.
6.CE/FC listed,competitve price.effective delivery.
Our packing for option
