Help CenterXY-3 Mining Coal Exploration Drilling Rig
Related Products
-
HGY-200 Mining Exploration Drilling RigUS$ 1 - 2MOQ: 1 Set -
HGY-300 Mining Exploration Drilling RigUS$ 1 - 2MOQ: 1 Set
-
Mineral Exploration Drilling Rig (HGY-1500T)US$ 1 - 2MOQ: 1 Set
-
HGY-300 Mining Coal Exploration Drilling MachineUS$ 1 - 2MOQ: 1 Set
-
Hot!!! HGY-1500A Exploration Drilling RigUS$ 1 - 2MOQ: 1 Set
Mining Exploration Drilling Rig
Features:
1) Compact in structure and light in weight.
2) High reliability, good performance and durability.
3) Common auto parts, such as clutch, transmission case and shifting structure.
4) Safe and reliable operations with synchronizer for shifting while the rig is running.
5) Be attached to the tower.
Technological Data of Drilling Rigs:
Model |
Mining Exploration Drilling Rig(HGY-650) |
Drilling depth( m) |
650 |
Spindle speed( r/min) |
Positive rotation rate: 65 117 201 309 440 187 338 582 894 1273 Reverse rotation rate: 72 207 |
Spindle stroke(mm) |
600 |
Lifting power max( KN) |
80 |
Driving force max(KN) |
60 |
Spindle output torque max(N.M) |
3435 |
Spindle hole diameter( mm) |
Φ65/Φ95 |
Lifting speed( m/s) |
0.43 0.78 1.35 2.08 2.95 |
Lifting capacity(single) max(KN) |
33 |
Diameter & Length of drum(m) |
Φ15*90 |
Movable cylinder stroke (mm) |
400(+-10) |
Max distance from hole (mm) |
250 |
Gear oil pump model |
CB-F32C-FL |
Nominal displacement( ml/r) |
32 |
Nominal pressure( MPa) |
16 |
Oil pump nominal rotation velocity(r/min) |
1800 |
Electromotor model |
YB200L-4 |
Power( kw) |
30 |
Diesel engine model |
K4100ZD |
Power( kw) |
36 |
Weight(power unit excepted)(Kg) |
1550 |
Overall dimensions(mm) |
2400*1020*1700 |
For Mining Exploration Drilling Rig , you also need drill tools as flow:
Production
Our company has produced drilling equipments for 50 years. We have passed ISO9001:2008, TS16949, CE Certification, MA Certification, High-tech Enterprise Certification.
The rigs are widely used in the construction of the projects e. g. prospecting, railway, road, port, bridge, water conservancy and hydropower, tunnel, well, industrial and civil construction, geological exploration, large diameter boring pile and small diameter diamond core deep hole drilling, etc. The main products are engineering geological drilling rig;water well drilling rig; vertical shaft 100, 200, 300, 650, 1000, 1500m rigs, full hydraulic power head 1000, 2000m rigs. At the same time, we produce drill bits and drill tools matching with the drilling rigs. Many rigs and drill bits possess patent certificates. Our products have exported to many countries of world. Such as Nepal, India, SriLanka, Afghanistan, Malaysia, Iran, Sudan, Chile etc.
