Specifications
1.Frequency: 850/900/1800/1900MHz2.640 x 480 pixels
3.can transmit mass data and never lost package.
4.easy to use ,convenie
KB1000 GPRS wireless camera system adopts GPRS communication mode, it can send the real-time images back to monitoring center or monitoring clients. There is no distance limit and can be used worldwide. The system is special used for security, metering, remote control etc. It is easy to use ,convenient operation, and highly practical.
system characteristics
Stable performance,can transmit mass data and never lost package. |
|
|
High speed transmission, One 640 x 480 pixels photo can be finished within 10 seconds |
|
Mature,stable and reliable server software, the software is development and application for several years and supports Mass data transfer. |
|
Publishing software is easy to operate, the interface is hommization and users are extremely easy to understand and operate; |
|
Receive software automatically displays the site’s GPRS is online or offline,as well as the state of receiving process. |
|
Supports both remote control taking picture and on-side trigger taking picture |
|
Easy to receive photos,as long as user installed the software in any of computer with internet can receive on-site pictures taken . |
|
Safe and reliable,software users have a strict password authentication pany ID passed server authentication,user passed database of account authentication. |
|
Communication
|
Frequency: 850/900/1800/1900MHz, can be suit for every country all over the world (Including North Amercia and South America) |
|
Advanced and strict data communication protocol, with the function of correction and encryption. Never lose package when data transmission |
|
IP auto-enrollment mechanism, can achieve a variety of service models and build a complete ultra-large-scale wireless application system. |
|
IO switching value function: Two channels input, two channels IO output. Remote control and reading. Alarm status threshold, automatic alarm signal report function |
|
Strong server software support, application for many years, strong function. |
|
Supply DTU work status interface, user can estimate DTU’s work status anytime; |
|
Strong communication backup function: Support switchover automatic between main server and backup server |
Industrial design |
Independent research and developing, embedded 32 bit ARM7-CPU with real-time operating system |
|
Standard industrial products, EMC anti-jamming design, strong adaptiveness |
|
Industrial class design and components to meet harsh environmental requirements |
|
Operation |
Remote sleep and awake: User can use appointed cell phone number to dial can sleep or awake DTU, it is convenient for user to save a lot of GPRS Flow Fee when no need to use DTU |
|
Remote modify DTU parameters by network(data service center) |
|
Adjustable Heartbeat interval and timeout |
|
Flexible data link modes for varied applications |
|
Support hardware and software Watch Dog Timer |
|
Powerful data service center testing tool |
technical parameters
|
Resolution:160×120, 320×240, 640×480 |
|
Output format:JPEG |
|
Minimum illumination:1 lux |
|
Lens:6MM IR |
|
WB:automatic |
|
Exposure:automatic |
|
Visual angle:60 degree |
|
Night vision open illumination:5Lux |
|
Figure night vision image:black and white |
|
Night vision distance:3-5 meters |
|
Environment conditions:Outdoor monitoring |
|
Output:RS232 |
