TM-IR5825 large IR infrared drying machine printing equipment
This IR drying machine printing equipment is widely used in machinery, here are some informations of this drying machine printing equipment
Parameter |
Power/Specification |
Remarks |
Dryer Length |
5.8 Meter |
|
Dryer Width |
1.25 Meter |
|
Belt Width |
1 Meter |
|
Belt Type |
Teflon Belt |
|
In-feed |
0.75 Meter |
|
Out-feed |
1.05 Meter |
4 cooling fans on exit |
Total Oven |
2 Pcs |
|
Total Oven Length |
4 Meter |
|
Each Oven Length |
2 Meter |
9 Tubes/ Oven |
Total Tubes |
18 Pcs |
|
Tube Type |
Ceramic |
|
Tube Power |
1000 W each |
|
Working Power |
3 Phase- 380V/50Hz |
|
Belt Motor Power |
90W- 5IK90RGU-CF |
Brand- OTG/VTV- 220V/50Hz AC |
Contactor |
90 Amp- 2 Sets |
Brand- Chint/Delixi |
Temp Range |
0- 250 Degree C |
|
Temp Tolerance |
+/- 5 Degree C |
|
Common Remarks:
All Belt rollers/ belt adjustable rollers should be with best grade nickel
Each machine should have one MCCB inside of control panel
Each machine Belt Speed Control should be stable, noise free belt transmission
Each oven should be controlled by individual Temperature Control Unit
