Home > Products > Tunnel Infrared Dryer > TM-IR3000-20 Glass infrared tunnel dryer for paper bag
TM-IR3000-20 Glass infrared tunnel dryer for paper bag
- 100 Set / Sets per Month
- Shenzhen
- T/T Credit Card PayPal
Product Details
| Condition: | New | Type: | Drying Oven | Place of Origin: | Guangdong, China |
| Brand Name: | Tamprinter | Model Number: | TM-IR3000-20 | Voltage: | 150W/220V*20 |
| Power(W): | 70KW | Dimension(L*W*H): | 3200*1900*1240Mm | Weight: | 3000kg, 3000kg |
| Certification: | CE ISO | Warranty: | 1 Year | After-sales Service Provided: | Overseas third-party support available |
Packaging Details
paper bag dryer will packaged by wooden box/iron box/carton as required
Product Description
TM-IR3000-20 Glass infrared tunnel paper bag dryer
TM-IR1500-15 paper bag dryer is widely used in printing machinery, here are some informations
| L*W*H | 3200*1900*1240MM |
| sus Belt to earth | 0.75M |
| Total wattage | 70KW |
| Wind fan wattage | 150W/220V*20 |
| Conveyer motor wattage | 90W/1P/220V |
| ConveyEr speed | 0~25m/min |
| Speed adjustment | Stepless |
| Heater Lamp wattage | 1.5Kw/220V×45pcs |
| Max height of production | 100mm |
| Weight | 3000kg |
| Conveyer width | 2000mm |
| Entering length | 1m |
| Heat area | 10m |
| Cool area Length | 3m |
| Exit length | 1m |
| Total Length | 15m |
+
15m glass infrared tunnel dryer Technology
Tamprinter Infrared Convection Oven ( shortwave )
1 imported shortwave infrared light radiation heating tube furnace used in all mirror panel system , equipped with special light tube reflector , can be 100% of all light reflection to the surface.
(2) using a uniform hair dedicated exclusively internal circulation duct temperature is very uniform.
3 equipped with imported light pipe dedicated controller, the frequency of light waves even control, the light pipe 100% to play full-wave energy, using current stable of 100% energy saving effect.
4 stainless steel chain and belt driven , easy to go astray , to load heavy metal category of products, with a special adjustment of the speed and stability.
5 light wavelength 0.76-1.6um, the strongest penetration , suitable transformer plant , electrical plant and other metal coil dipping baked or roasted dispensing electronic products .
Tamprinter Infrared Convection dryer ( MW )
1 medium-wave infrared light tubes imported radiant heating furnace used in all mirror panel production, with special reflector tube light , can be 100% of all light reflection to the surface.
(2) using a uniform temperature of the inner loop hair exclusive special duct temperature is very uniform.
3 equipped with imported light pipe dedicated controller, the frequency of light waves even control, the light pipe 100% to play full-wave energy, using current stable of 100% energy saving effect.
4 imported Teflon Wimbledon with a high resistance to rotation , suitable for the size class range of products , with a power converter, speed and stability .
5 light wavelength 0.76-3.6um, the surface absorbed the best baked products , such as glass, printing, textile printing , spray drying surface coating industry .
Tamprinter Infrared Convection tunnel
Drying principles outlined
Conventional oven heating pipe heating using heat from the heated surface of the object to its internal thermal conductivity , so the heating process is slow, uneven heating , and some products first love hot conjunctival surface cause internal moisture can not get out , easy to produce bubbles or deformation.
Infrared Convection Oven is the use of energy efficient infrared light tubes imported produce infrared electromagnetic radiation directly to the object , so that objects within the molecular oscillation , internal and external heat simultaneously ,quickly and thoroughly remove the moisture inside the object , the surface will not get out of the water inside the first dry produce surface blistering, internal roasted quit and so on.
Energy efficient advantages:
1 Energy: Infrared Convection Oven power than ordinary furnace small 1 / 3 , warming fast start ( 2-10 points can be raised to 200 degrees ) , the thermostat automatically reduces small current wave ( energy savings of 30% -70 % )
(2) Efficient : Infrared Convection Oven direct radiation makes the product molecular oscillation product , so the product simultaneously inside and outside heat, fast drying product moisture , direct -saving 5-10 times .
(3) quality and stability : infrared light to heat pipe heat inside and outside at the same time , the internal water discharged in time , the product surface is not easy to blister, uniform color appearance .
4 Green Explosion : Infrared Convection Oven baking time is short, short residence time before curing , the time to reduce pollution and harmful gases discharged in time , not stuffy harmful in the furnace , the furnace safe and clean , easy to produce flammable gas deflagration and other risks
Company Profile
Tamprinter printing machinery group limited is one of the most professional special printer supplier of Plastic Field in China. We have supplied OEM service for the domestic counterparts since 2003. OEM products have been achieved CE certification.
Due to business expansion, Shenzhen Tamprinter printing machinery limited International trade department have been separated from the parent company in March 2013.
Key products: Pad printer, Screen printer, UV curing machine, Heat transfer machine.
Major market: Globle.
Business scopes:
1. Research, develop, produce and sell: Pad printer, Screen printer, Heat transfer machine, Hot stamping machine, Pre-post printer(UV curing machine, Flame treatment machine ,UV exposure clich machine, Coating emulsion machine, Silk mesh tighten machine, Screen stencil drying oven, Silk screen frame exposure machine, Steel pad plate oven, IR oven, IR drying tunnel conveyer, ) ;
2. Trade and authorize for the patent of the above products, Services about design, testing, maintenance, and technical consulting ;
3. Valet Manufacture: flame treatment gun,screen frame, Screen Stencil,pad, steel plates, film , Drying Racks Trolley and the relative moulds, jigs and parts;
4. Sale by proxy the relative supporting materials: printing ink, Ink Adjustment tool, Rubber pads Materials, Pad Printing Blade, ink cup and ring, Pad holder, ink roller, Screen Silk, Aluminium Screen Frame, Rubber Squeegee, sensitive emulsion, Emulsion Coating tool, Etching powder, Sensor Switch, Tension meter,Spraying gun, Circuit board, Inkwell, Solenoid Valve, hot stamping foil ,High temperature tape,Stamp plate,Silicon rubber roller,Heat transfer paper,High temperature glue, UV lamp ,UV lamps Trigger etc;
5. Our engineer can communicate with clients at anytime in english, design development use UG, Proe, Autocad, Mastercam ;
6. Import and export business of the above items.
