TM-VF Variable Frequency Waterbased Heat Transfer Paper Drying Tunnel
US$ 1 - 20,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Drying Oven
Place of Origin:
China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
TM-IR6 IR Drying Tunnel OvenUS$ 1 - 10,500MOQ: 1 Set -
TM-Iry Drying IR Tunnel OvenUS$ 1 - 5,500MOQ: 1 Set
-
TM-IR1200 Automobile Glass Shortwave Infrared Tunnel OvenUS$ 16,888 - 16,900MOQ: 1 Set
-
Infrared Drying TunnelUS$ 1 - 25,000MOQ: 1 Set
-
TM-UVIR UV and IR Combined DryerNegotiableMOQ: 1 Set
Condition
New
Type
Drying Oven
Place of Origin
China
Brand Name
Tamprinter
Model Number
TM-VF
Voltage
380V
Power(W)
6kw
Dimension(L*W*H)
3000*1600*1600
Weight
1000kg
Certification
ISO9001:2008
Warranty
1 Year
After-sales Service Provided
Overseas third-party support available
TM-VF Variable Frequency waterbased heat transfer paper drying tunnel
This large infrared tunnel is one of our hottest-selling machine, and is widely use in printing machinery, here are some informations of this large infrared tunnel
| Conveyer width | 800mm |
| Total wattage | 21KW |
| Wind fan wattage | 500W*6 |
| section | 3 sections |
| Conveyer speed | 0~25m/min |
| Speed adjustment | Stepless |
| U Heater Lamp wattage | 1.5Kw/220V×6pcs |
| Max height of production | 100mm |
| Total Length | 11m, Heat length: 9m |
| heating tube power |
35*500w |
1. Dimension:9*1.6*1.6m
2. Belt width:800mm
3. Temperature:RT-150℃
4. Sections:3 sections
5. Air flows:2/3 back to keep the temperature,1/3 to eject the moist air
6. Total power:21kw
7. Air motor power: top air motor 500w, bottom air motor 500w. (each section)
8. Heating tube:12pcs/section
9. Heating tube power:36*500w
10. Belt Material: Teflon
11. Cylinder to open the cover
