IR-T200 IR Tunnel Oven Conveyor T-shirt Drying Machine
Model |
IR-T650 |
IR-T400 | IR-T200 |
Conveyor(L*W*H) |
1800*900*1280mm |
1800*750*1280mm | 1000*460*465mm |
The drying zone(L*W) |
800*900mm |
800*750mm | 520*460mm |
Conveyor belt width |
650mm |
400mm | 200mm |
The biggest conveyor width |
750mm |
450mm | 250mm |
The biggest conveyor height |
100mm(Adjustable) |
100mm(Adjustable) | 100mm(Adjustable) |
Conveyor belt(material) |
PTFE(Teflon) |
PTFE(Teflon) | PTFE(Teflon) |
Conveyor belt(speed) |
1-5meter/minute |
1-5meter/minute | 1-5meter/minute |
IR Lamp |
500W, 8 pcs,Heraeus (Adjustable) |
500W, 6 pcs,Heraeus (Adjustable) | 300W, 6 pcs,Heraeus (Adjustable) |
Power of generator |
90W(stepless speed regulation) |
90W(stepless speed regulation) | 90W(stepless speed regulation) |
Total Power |
4100W, 220V,SINGLE PHASE |
3100W, 220V,SINGLE PHASE | 1860W, 220V,SINGLE PHASE |
G.W |
200KG |
160KG | 100KG |
T-shirt ir tunnel oven is Flash Drying Equipment
Small conveyor dryer Feature
1. Cover small area,easy to use
2. Teflon screen belt , customers' designs are welcome.
3. Motor can be set to any speed and provides a smooth and even motion.
4. Far infrared heating pipe is especially suitable for solidifying heat-set and special type of printing ink.
5. Adjustable belt speed and tunnel temperature controls.
Tamprinter Printing Machinery Group Limited
As one of the most professional special printer supplier of Plastic Field in China,we have supplied OEM service for the domestic counterparts since 2003. OEM products have been achieved CE certification.
Due to business expansion, Tamprinter printing machinery limited International trade department have been separated from the parent company in March 2013.
Key products : Pad printer, Screen printer, UV curing machine, Heat transfer machine.
Advantages:
1. All the electrical components and control system are from Germany and Japan, guarantee the stable quality of the print.
2. Multi-purpose microcomputer operating panel and touch screen operation can easily achieve man-machine dialogue.
3. As high quality steel frame structure and High temperature of the lacquer that bake, so that our printer is light and solid, beautiful and practical.
Market Area:
More than 80 countries. Encluding Europe, the United States, Canada, Southeast Asia, the Middle East, etc. We cooperate with Omron, Emerson and Ruigao light, which are the world famous enterprises.
