Computer Thin Blade Slitting Machine
Feature
Designed speed: 150-250m/min
Available width: 1600mm-2500mm
Slitting precision:+_1mm
NC Thin Blade Slitter Scorer
1.NC control; quickly put blades in order in 3-10 seconds; colored man-machine interface.
2.Electrically control scoring depth; Automatic conversion from multi-scorer wheels combination;
3.Slitting and scoring are independently driven; pneumatically lifting up and down;
4.Automatic blade grinding; electrically rectify deviation.
5.999 orders can be input.
6.Trimming wind suction system is optional.
7.Pre-printing recognition tracing system is optional.
Technical Parameter
Model |
2200 |
2600 |
Machine dimension (mm) |
3700x1700x2340 |
4100x1700x2340 |
Power (KW) |
16 |
16 |
Max slitting width (mm) |
1900 |
2300 |
Min slitting width (mm) |
140 |
|
Min scoring width(mm) |
0 |
|
Scoring height (mm) |
0-10 |
|
Blade (mm) |
200x122x1.2 |
|
Blade &Scoring Composed |
Five Blade Eight scoring |
|
More Picture
Packaging&Shipping
