Shanhua Yuchai 400kva Silent Generator Generator

Name: Shanhua Yuchai 400kva Silent Generator Generator
Brand: Shanhua
SKU: 120849167

US$ 240,000 - 380,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Shanhua

Model Number:

HL400GF

Shandong Huali Electromechanical Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name Shanhua

Model Number HL400GF

Output Type AC Three Phase

Speed 1500RPM

Frequency 50HZ

Rated Power 320Kw/400Kva

Rated Voltage 400/230/380/220/450/415V

Rated Current 576A

Specifications

Shanhua Yuchai 400kva silent generator generator
>With 1 year after sale service;
>about 20 years experience.

Shanhua Yuchai 400kva silent generator generator

Technical Dates for Shanhua Yuchai 400kva silent generator generator

2. Specification of diesel engine

Engine brand				Yuchai
Engine model				YC6K500L-D30
Number of Cylinders				6
Cylinder arrangement				Vertical in-line
Cycle				Four stroke
Aspiration				Turbocharged
Bore×Stroke (mm×mm)				129x 155
Displacement (Liter)				15.8
Compression Ratio				15:1
Speed Governor				Mechanical
Cooling System				Water-cooled
Fuel Consumption at 100% Load (g/Kw.h)				200
Starting Method				DC24V starting

3. Specification of alternator
Alternator brand				Stamford
Alternator model				LVI634E
Number of Phase				3
Connecting Type				3 Phase and 4 Wires
Number of Bearing				1
Protection Grade				IP23
Altitude				≤1000m
Exciter Type				Brushless ,Self- exciting, AVR automatic voltage regulating,100% Copper winding wire
Insulation Class				H
Telephone Influence Factor (TIF)				≤50
THF				≤2%
Voltage Regulation, Steady State				≤±1%
Transient State Voltage				≤-15%~+20%

4. Cnotrol System (with ComAp MRS 10 Controller)
Operating temperature :-20°C~60°C Relative Humidity : 95% Operating voltage :DC24V ( range :18-30V, pressure :50V/5 mm )
General functions and features of ComAp MRS 10 Controller
Control screen is small, reliable performance, simple operation, the internal circuits clear, easy detection. With automatic detection and protection features protect the engine safe and stable operation. Multi -interface display unit work and alarm state, intuitively clear, LCD displays the parameters of diesel engines. Microcomputer can be set on the control panel input, output, alarm, delay and other parameters. Maintenance, manual, automatic and other modes of operation. No non-normal electricity supply automatic starting, generator fault protection off, to provide historical state records. Generator over / under voltage, generator frequency / high frequency generator speed due to speed / over speed, low oil pressure, high temperature, emergency stop, battery over / under voltage, over current / short circuit protection function.
