High Efficiency Wire Coating Equipment With Output 40-100m/min
- qingdao
- T/T Money Gram Credit Card PayPal
You May Like
-
Inber Nail Making Equipment Plant From China
-
Chicken Cow Manure Fertilizer Machine Pellet
-
Professional Machines for Making Nails and Screws Nail Making Machine
-
Professional Supplier From China Fertilizer Granules Making Machine
-
Granulator Equipment Organic Fertilizers
-
High Speed Nail Manufacturing Machinery Factory
Product Details
| Condition | New | Type | Coating Production Line | |
| Substrate | Steel | Coating | Other, PVC coating | |
| Place of Origin | Henan, China | Brand Name | inber | |
| Model Number | INBJ | Voltage | could customize | |
| Power(W) | 4*1.5kw | Dimension(L*W*H) | 2000mm*900mm*1500mm | |
| Weight | 380kg | Certification | ISO | |
| Warranty | 1year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Automatic PVC wire coating machine
Our PVC wire coating line apply to PE, PVC, rubber etc. adopts thermoset extrusion to isolation
the wire core, then through change the different mechanical headstocks and dies, we can get the
steel wire that the customers need.
The main machine barrel and screw adopt 38CrMoAl material, are made through twice nitrogen
treatment, which can extend the machine service life. This machine line is the ideal products of
PVC wires and cables manufactures.
Raw materials | PP , PVC , PS ,PE,PA,etc |
Screw diameter | Φ30mm |
Screw diameter ratio | 26: 1 |
Screw materials | 38CrMoACA Nitride steel, nitriding processing |
motor | P=2.2Kw frequency |
reducer | hard-toothed surface reducer |
Heating power | 4×1.5Kw |
Coating thickness | 0.05mm-2mm |
Cooling type | Stainless steel cooling thank |
Suitable wire diameter | 0.6-2.5mm(could reach 5mm wehn making wire roll) |
capacity | 40-100m/min(related to materials) |
Length control | 200-1000mm(could also be roll if not cutting) |
Machine size | 2000mm*900mm*1500mm |
Machine weight | About 380KG |
Quality guarantee term is for one year. Malfunctions which are caused by machine-self and quality will be responsible for our manufacturer. Other malfunctions which caused by operation mistakes, man-made problems, etc will be responsible for clients-sef.
30% By T/T asdeposit to start order.
70% as balance when offering copy B/L.
Any interest, pls contact with me freely.
