LUDC High Accuracy Smart Type Low Price Vortex Shedding Flow Meter

LUDC High Accuracy Smart Type Low Price Vortex Shedding Flow Meter thumbnail-1
LUDC High Accuracy Smart Type Low Price Vortex Shedding Flow Meter photo-1
US$ 1 - 10,000 MOQ: 10000 Sets
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Mingzhou
Model Number:
MP-LUDC
Contact Supplier Request Quote Chat Now
Wuxi Mingzhou Environmental Protection Machinery & Equipment Factory
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name Mingzhou
Model Number MP-LUDC

  MP-LUDC Series Vortex Shedding Flow meter




Product Description



LUDC Series Vortex Shedding Flow meter is used in the flow measurement of the fluid in the industrial pipe line,

such as gas, liquid, steam, etc. . lts characteristics are less pressure loss, no movable mechanism in the meter.

This flow meter adopts piezoelectric sensor,  has high reliability, works with in -20°C rang to + 250°C. There are standard analogue signal (4to2OmA) or pulse signal outputs, it is easy to be used together with digital systems,

such as computer, etc. It’s a more advanced and ideal flow meter.



Technical parameters

Medium

LUDC

Medium

Air, liquid, steam

Diameter

Wafer type

15, (20), 25, 32, 40, 50, 65, 80, 100, 125, 150

Flange connection type

200

Flow rate

Normal flow velocity range

Gas 5-50m/s Liquid 0.5-7m/s

Normal flow rate range

Liquid, gas, steam type flow range refer to table 2,3 as follows

Accuracy

Liquid ±1% ,  or gas (steam) ±1.5%

Medium temperature

Normal temperature   -25°C~80°C,  Heat temperature -25°C~250°C

Working pressure

1.6MPa; 2.5MPa;4.0MPa(Supply as order's requirement)

Output signal
(signal cable
connection is
M20x1.5)



Pulse voltage

Output signal





High level 8-10V  Low level 0.7-1.3V

(Ex-proof version: High level 4-5V  Low level 0.7-1.3V)



Duty ratio of pulse is about 50%, transmission distance 100 meters.



Standard

current output signal



Allowable external load resistance less the 600 Ω(24VDC)                           Transmission distance is 3000 meters

Working environmental condition

temperature   :  -25°C~+55°C     humidity  :  5-90%  RH50°C

Material

Meter body :  1Cr18Ni9Ti  Converter  housing :  AL-allog

Power supply

24V  DC±10% ;   Or dual lithium battery 3.6 V 7.5 Ah

Protection grade

IP65

 LUDC high accuracy smart type Low price Vortex Shedding Flow meter
