Home > Manufacturing & Processing Machinery > Mining Machinery > Mining Crusher > China Jaw Crusher

China Jaw Crusher

Name: China Jaw Crusher
Brand: Hysan
SKU: 120596047
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Type:

Jaw Crusher

Application:

stone,ore,limestone,CACO3,ore,concrete,granite

Contact Supplier Request Quote Chat Now

Shandong Hysan Road&Bridge Mechanical Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Jaw Crusher

Application stone,ore,limestone,CACO3,ore,concrete,granite

Motor Type AC Motor

Power(W) 200

Capacity(t/h) 500T/h, 5-800

Place of Origin Shandong, China

Brand Name Hysan

Model Number PE1200*1500

Dimension(L*W*H) 4100*3120*3900

Weight 75T

Certification ISO9001-2008

Warranty one year excluding wearing parts, whole using life

After-sales Service Provided Engineers available to service machinery overseas

Specifications

Jaw Crusher
1.ISO9001:2008
2.Crusher capacity:5-800T/H
3.Long useful life
4. suitable for primary and secondary crushing

Jaw crusher

The working part of the jaw crusher is two pieces of jaw plate, one is stationary and fixed on the front wall of machine body, which is called fixed jaw, while the other one, swing jaw, making a crushing chamber with the fixed jaw, moves back and forth periodically. When separating, the material enters into the crushing chamber and then the particle drops out from the bottom; when combined, the material is crushed by the compressive force, buckling and split effect from the jaw plate. The jaw crusher series are used for the primary and secondary crushing of hard material. There are two types of crusher, including coarse jaw crusher and fine jaw crusher.

Jaw crusher Parameters

modeL	Feeding port size (long×width)(mm)	Discharging Mouth size (mm)	Biggest feeding granularity (mm)	Production (T/h)	Eccentric shaft speed (r/min)	Motor power (KW)	Envelop dimensions (long×width×high) (mm)
SHPE-400×600	400×600	40-100	350	14-36	275	30	1650×1715×1591
SHPE-500×750	500×750	50-120	425	30-80	250	55	2250×1980×1920
SHPE-600×900	600×900	75-200	500	56-192	250	55	2560×1840×2320
PEX-250×1000	250×1000	20-50	210	15-50	300	30	1550×1990×1370
PEX-250×1200	250×1200	20-60	210	20-70	250	37	1530×2285×1625
ZG-PE-250×400	250×400	20-60	200	8-16	300	15	1430×1316×1296
ZG-PE-400×600	400×600	40-100	350	14-36	275	30	1700×1732×1656
ZG-PE-500×750	500×750	50-120	400	30-80	250	55	1900×1876×1821
ZG-PE-600×900	600×900	75-200	480	56-192	250	55	2280×2245×2320
ZG-PE-800×1100	700×1100	80-200	600	70-195	250	75	2550×2280×2380
ZG-PE-750×1060	750×1060	80-235	630	105-195	250	90	2655×2302×3110
ZG-PE-900×1200	900×1200	95-265	750	90-220	220	110	3800×3160×3050
ZG-PE-1100×1400	1100×1400	150-300	1000	150-340	180	160	4200×3020×3900
ZG-PE-1200×1500	1200×1500	150-300	1100	200-500	180	200	4100×3120×4155
ZG-PEX-150×750	150×750	10-40	120	8-25	320	15	1210×1572×1045
ZG-PEX-250×1000	250×1000	20-50	210	15-50	330	30	1550×1990×1370
ZG-PEX-250×1200	250×1200	20-60	210	20-70	320	37	1530×2285×1625
ZG-PEX-300×1300	300×1300	30-80	250	30-90	330	45	1530×2380×1720
ZG-PEX-300×1500	300×1500	35-100	250	40-120	320	55	1900×2600×1780
ZG-PEX-350×750	350×750	20-80	300	30-52	320	37	1650×1680×1655

Jaw crusher Advantages:

Less noise and dust.
High crushing ratio, uniform particle size.
Simple structure, safe work, low operating cost.
Safe lubrication system, easy parts replacement and equipment maintaining.
Deep crushing chamber with no dead zone, improves the feeding size which leads to a high capacity.
Equipment energy-saving: save 15%-30% energy, save system energy more than twice.
Wide range of discharge gate can meet the requirements of different customers.
Gasket discharge gate adjusting device makes it more convenient to use. Wide adjustable range improves the flexibility of the equipment.
