Coarse Crusher, Coarse Jaw Crusher

Coarse Crusher, Coarse Jaw Crusher thumbnail-1
Coarse Crusher, Coarse Jaw Crusher photo-1
US$ 4,000 - 5,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Jaw Crusher
Application:
stone,ore,limestone,CACO3,ore,concrete,granite
Contact Supplier Request Quote Chat Now
Shandong Hysan Road&Bridge Mechanical Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Jaw Crusher
Application stone,ore,limestone,CACO3,ore,concrete,granite
Motor Type AC Motor
Power(W) 200
Capacity(t/h) 500T/h, 5-800
Place of Origin Shandong, China
Brand Name hysan
Model Number PE1200*1500
Dimension(L*W*H) 4100*3120*4155
Weight 75T
Certification ISO9001-2008
Warranty one year excluding wearing parts, whole using life
After-sales Service Provided Engineers available to service machinery overseas

Specifications

coarse jaw crusher
1.Short toggle
2.Low hanging
3.Big swing angle.
4.Long useful life

stone crusher



The  jaw crusher  has a feature of big crushing ratio, uniform finished product size, simple structure, reliable operation, easy maintenance, low operation cost. Jaw crusher is preferred equipment for the complete set of product line as the first step crusher.

Jaw Crusher applications
The PE series  jaw crusher is widely applied in mine, metallurgy,chemical industry, building, highway,water conservancy, light industry to crush or break various kinds of stones with compressive of not more than 350Mpa.




Stone Jaw Crusher working Principle

The PE serial jaw crusher mainly consists of main frame, movable( swing ) jaw, eccentric shaft, toggle plates etc. The electric motor passes power via V-belt pulley to the eccentric shaft to make the movable jaw moves in mesh, therefore, materials in crushing chamber can be crushed.



Stone Jaw Crusher Technical Parameters



modeL

Feeding port size

(long×width)(mm)

Discharging

Mouth size

(mm)

Biggest feeding granularity

(mm)

Production (T/h)

Eccentric shaft speed

(r/min)

Motor power

(KW)

Envelop dimensions (long×width×high)

(mm)

SHPE-400×600

400×600

40-100

350

14-36

275

30

1650×1715×1591

SHPE-500×750

500×750

50-120

425

30-80

250

55

2250×1980×1920

SHPE-600×900

600×900

75-200

500

56-192

250

55

2560×1840×2320

PEX-250×1000

250×1000

20-50

210

15-50

300

30

1550×1990×1370

PEX-250×1200

250×1200

20-60

210

20-70

250

37

1530×2285×1625

ZG-PE-250×400

250×400

20-60

200

8-16

300

15

1430×1316×1296

ZG-PE-400×600

400×600

40-100

350

14-36

275

30

1700×1732×1656

ZG-PE-500×750

500×750

50-120

400

30-80

250

55

1900×1876×1821

ZG-PE-600×900

600×900

75-200

480

56-192

250

55

2280×2245×2320

ZG-PE-800×1100

700×1100

80-200

600

70-195

250

75

2550×2280×2380

ZG-PE-750×1060

750×1060

80-235

630

105-195

250

90

2655×2302×3110

ZG-PE-900×1200

900×1200

95-265

750

90-220

220

110

3800×3160×3050

ZG-PE-1100×1400

1100×1400

150-300

1000

150-340

180

160

4200×3020×3900

ZG-PE-1200×1500

1200×1500

150-300

1100

200-500

180

200

4100×3120×4155

ZG-PEX-150×750

150×750

10-40

120

8-25

320

15

1210×1572×1045

ZG-PEX-250×1000

250×1000

20-50

210

15-50

330

30

1550×1990×1370

ZG-PEX-250×1200

250×1200

20-60

210

20-70

320

37

1530×2285×1625

ZG-PEX-300×1300

300×1300

30-80

250

30-90

330

45

1530×2380×1720

ZG-PEX-300×1500

300×1500

35-100

250

40-120

320

55

1900×2600×1780

ZG-PEX-350×750

350×750

20-80

300

30-52

320

37

1650×1680×1655



coarse crusher, coarse jaw crushercoarse crusher, coarse jaw crushercoarse crusher, coarse jaw crusher
