Specialities:
1, 4mm-12mm GT4-12A hydraulic automatic steel bar straighten and cut to length machine
2,HIGH efficiency, hydraulic system, advanced technological standard, good dustproof performance, two kinds of speed regulation
3.reliable SGS,CE,TUV,BV
4mm-12mm GT4-12A hydraulic automatic steel bar straighten and cut to length machine features:
1. Use the international advanced rotary straightening structure, combined with domestic usage.All the spare parts adopt imported machining center, to guarantee the machining size, to ensure the quality of the whole machine
2. All hydraulic components are imported from Taiwan, to overcome bad work environment and ensure that the hydraulic system can long-term operate stably
3. Configure special oil pump with domestic well-known brand "the Yellow River cyclone" motor with high pressure, large flow as the power, make sure cut off power stronger and faster
4. All the electrical components are provided by CHNT
5. Human intelligent control system, simple operation, more efficient
6. Import terminal with shake safety, durable and waterproof
7. All roller adopt high quality alloy steel with high hardness and good wear resistance to improve the service life
8. The machine can realize continuous production, high efficiency, can input 99 batches at the same time
9. Oil cylinder spring USES the German high quality import spring, spring warranty for one year
10. The strict test run before delivery, powerful guarantee the quality of the machine
4mm-12mm GT4-12A hydraulic automatic steel bar straighten and cut to length machine with fast straightening and cutting speed, adopting advanced straightening standrad, it is the ideal rebar processing equipment. CHOOSING US,CHOOSING QUALITY AND PERFECT AFTER-SALE SERVICE!
4mm-12mm GT4-12A hydraulic automatic steel bar straighten and cut to length machine related products
Mode |
GT4-12A |
GT4-12B |
GT4-12C |
GT4-12D |
GT4-14D |
GT4-14A-1 |
Common carbon steel |
Φ4-12 |
Φ4-12 |
Φ4-12 |
Φ4-12 |
Φ4-14 |
Φ4-14 |
III screw steel |
Φ4-10 |
Φ4-10 |
Φ4-10 |
Φ4-10 |
Φ4-12 |
Φ4-12 |
Cut length(mm) |
300-9000 |
300-9000 |
300-9000 |
300-9000 |
300-9000 |
300-9000 |
Traction speed(meter/min) |
30-40 |
30-40 |
30-40 |
30-40 |
45-48 |
45-48 |
Cutting tolerance |
±10mm |
±10mm |
±10mm |
±10mm |
±10mm |
±10mm |
Straightening tolerance |
±2mm |
±2mm |
±2mm |
±2mm |
±2mm |
±2mm |
General power (kw) |
9 |
9 |
7.5 |
7.5 |
9 |
9 |
Voltage |
380v |
380v |
380v |
380v |
380v |
380v |
Weight(kw) |
370 |
580 |
310 |
340 |
430 |
890 |
straightening and cutting materials
JOONNA MACHINERY CO., LTD, is founded in 1988, focusing on rebar cutting machine, bending machine and rebar straightening machine, and other rebar processing equipment.With 26 years’ development, today’s company integrates design, R&D,production, sales with independent rights to export and import.
After -sale service
JOONNA machinery three guarantees: If the whole machine suffers major quality problems such as engine body, box, and gear fracture, the warranty period is 6 months.Components and parts (nonconsumable parts) are under replacement and warranty within 3 months. If quickwear parts of the machine listed in the below table have problems, the quickwear parts are not in scope of three guarantees. (Remark: effective period is subject to date of invoice.)
