mutltipair top quality 24awg twisted custom color lan network cable

Specifications

1.27 years experience
2.24AWG copper
3. ISO 9001,ISO14001
4.Mino order:10boxes,customer's demands
5.FOB price:$0.1-$9/meter



Specifications:

1) Resistance (max): 9.50ohm/100m at 20°C
2) D.C. resistance unbalanced (max): 2.5%
3) Mutual capacitance (max): 5.6 nF/100m
4) Capacitance unbalanced (max): 330pF/100m
5) Impedance:1-100MHz 100±15ohm
6) Differential phase delay(max):30ns/100m;
7) Operating temperature:-20~+60°C
8) Permitted bend radius:10times diameter of the cable.
9) Pairs colors: 1) White/blue    2) White/orange         3) White/green     4) White/brown   5) white/grey

                             6)red/blue         7) red/orange              8) red/green        9)   red /brown   10   red /grey

                            11) black/blue   12) black/orange      13)black/green   14)black/brown  15)black/grey

                            16)yellow/blue   17)yellow/orange    18)yellow/green  19)yellow/brown  20)yellow/grey

                             21)violet/blue    22)violet/orange       23)violet/green    24)violet/brown    25)violet/grey
10) Materials: a) Conductor: 24 AWG copper
b) Insulation: solid HDPE
c) Sheath: PVC/PE/LSNHP



Packing:

1,000 feet (305m) per box 500m - 1000m per wooden reel Custom order lengths are available upon request



Application:

10 Base-T

100Base-T4

100Base-TX

100Base-VG-ANYLAN

155Mbps ATM

622 Mbps ATM

1000Base-T



Standards:

ISO/IEC11801

ANSI/TIA/EIA-568-B.2



Features of product:

1.more bandwith excess than 100MHz standard required;

ply with ROHS standard;

3.the products of special outer sheath or purpose can be designed according to customer's demands.



Cable structure:











Transmission performance:



frequency (MHz)	attenuation (Max) (dB/100m)	NEXT (Min.) (dB/100m)	PSNEXT (Min.) (dB/100m)	ELFEXT (Min.) (dB/100m)	RL (Min) (dB)	PHASE VELOCITY (Min)(m/s)	PHASE DELAY (Max) (ns/100m)
1	2	65	62	64	20	0.585c	570
4	4.1	56	53	52	23	---	552
10	6.5	50	47	44	25	0.611c	545
16	8.2	47	44	40	25	---	543
20	9.3	46	43	38	25	---	542
31.25	11.7	43	40	34	24	---	540
62.5	17	38	35	28	22	---	539
100	22	35	32	24	20	0.620c	538
