p10 outdoor single color led display module,p10 high brightness single color led module
Features:
1.Applications: The applications for Multi Line Displays are endless.
2.Up-dated Multi Line LED Electronic Displays are easy to use and can be up-dated quickly and with no technical expertise
3. Character heights: Available in a variety of character heights: although if you have a multi line display made up from a number of Bi-Line displays, you can show a single line of text in double height format which will usually double these heights. Larger height signs are also available.
4.Color:LED Colour Options are: RED, GREEN, YELLOW, or TRI-COLOUR, blue and white are also available
5.Various speed and Characters :The signs can display most different Characters and Graphic Symbols.
The signs can run at variable Speeds, and have various display features including Bold, Run Left/Right etc.
6.Can be controlled remotely , like WIFI, GSM, GPRS,3G,4G,5G
| module parameters | |
| Model | P10 |
| Pixel pitch | 10 mm |
| Pixel configuration | 1R |
| Pixel matrix per panel | 32*16pixels |
| Module resolution rate | 32*16=512dots |
| Module dimensions (W×H) | 320*160mm |
| Module dimensions (W×H) | 12.6*6.3 Inch |
| Weight | 0.7kg±0.05kg |
| Package material | Polycarbonate |
| Construction | combined driver board |
| Input votage | 4.8-5.5V |
| MAX. input current | 3.4A±0.1A |
| Driving mode | 1/4 constant votage scan |
| Module power | ≤17.0 W |
| cabinet parameters | |
| Brightness | ≥3000 cd/m2 |
| Cabinet dimensions (W×H×D) | 960*960*70 mm |
| Cabinet dimensions (W×H×D) | 37.8*37.8*2.76 Inch |
| Resolution ratio | 96*96=9216dots |
| Weight | 33.5±0.05 kg |
| Weight | 99.78±0.023 lbs |
| Pixel density | 3906 dots/m2 |
| Viewing angle (H/V) | 80±15 deg |
| Best viewing distance | ≥10m |
| MAX. power | ≤400W/m2 |
| AVE. power | 200W/m2 |
| control parameters | |
| Gray scale per color | 0-128 to optional |
| Colors | 256 |
| Life time | ≥100,000 hours |
| MTBF | ≥10,000 hours |
| Refresh rate | ≥ 75Hz |
| MAX. power | 1000 W/m2 |
| Input voltage (AC) | 110V ~ 240V |
| Operating temperature | -20°C ~+ 50°C |
| Operating humidity | 10% ~ 90% |
| Source compatibility (with video processor) | DVI/VGA,Vedio(mutiple modes),RGBHV,composite Vedio Single,S-VIDEO,YpbPr(HDTV) |
Single color module
| DIP series | |
| PH10 red color outdoor | module size 320x160 |
| PH10 yellow color outdoor | module size 320x160 |
| PH10 green color outdoor | module size 320x160 |
| PH10 blue color outdoor | module size 320x160 |
| PH10 white color outdoor | module size 320x160 |
| PH16 single color outdoor | module size 256x128 |
| PH12.5 single color outdoor | module size 400x200 |
| PF20 single color outdoor | module size 320x160 |
Testing room &Warehouse
Competitive Advantages:
1) Stable quality and fast Response;
2) Short delivery,effective production;
3) Sample order,trial order be acceptable;
4) Good communication;
5) 2 years warranty;
