cu core PVC Insulated overhead Electric BV Cable 450/750V for sale
1. Application:
This product is fit A.C rated voltage up to and including 450/750V.
2. Use:
The products can be used for power lighting or telecommunication equipment, household electric appliance, meter and instrument, etc.
3. Structure:
A: Copper Conductor
B: PVC Insulated
4. Production Standards:
GB/T5023.3-2008/IEC60227-3:1997
5. Conductor:
Copper
6. Insulation:
PVC(Polyvinyl Chloride)
7. Operating Characteristics:
A. Temperature should be above 0°C when laying the cables or wires. Bending radius allowed: a minimum 4D is required for cables that have an outer diameter less than 25mm, while other cables have a minimum requirement of 6D.
B. Long time working temperature of or below 70°C is required for all cables or wires, except Model No. BV-90 that can stand temperature up to 90°C.
C. Etc. with rated A/C voltage being 450/750V.
8. Specifications:
BV-450/750V | |||
|
Nominal Section (mm2) |
Approximate O.D. (mm2) |
Conductor Resistance (20°C,Ω/km) |
Approximate Weight (kg/km) |
1x1.5(A) |
2.8 |
12.1 |
19.5 |
1x1.5(B) |
2.9 |
12.1 |
20.8 |
1X2.5(A) |
3.3 |
7.41 |
30.8 |
1x2.5(B) |
3.6 |
7.41 |
31.5 |
1x4.0(A) |
3.8 |
4.61 |
45.6 |
1x4.0(B) |
4.1 |
4.61 |
47.1 |
1x6.0(A) |
4.3 |
3.08 |
65.3 |
1x6.0(B) |
4.7 |
3.08 |
68.5 |
1x10 |
6.0 |
1.83 |
111 |
1x16 |
7.1 |
1.15 |
169 |
1x25 |
8.9 |
0.727 |
265 |
1x35 |
9.9 |
0.524 |
359 |
1x50 |
11.1 |
0.387 |
485 |
1x70 |
13.5 |
0.268 |
685 |
1x95 |
15.8 |
0.193 |
946 |
1x120 |
17.4 |
0.153 |
1181 |
1x150 |
19.4 |
0.124 |
1453 |
1x185 |
21.6 |
0.0991 |
1821 |
1x240 |
24.6 |
0.0754 |
2383 |
1x300 |
27.5 |
0.0601 |
2983 |
1x400 |
30.8 |
0.0407 |
3800 |
