High Tension Armored Cable ,SWA, Armoured/Unarmoured PVC Underground Cable

Negotiable MOQ: 1000 Meters (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Hebei, China

Brand Name:

NBF

Model Number:

LV/MV/HV

Contact Supplier Request Quote Chat Now

Hebei New Baofeng Wire & Cable Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin/Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Hebei, China

Brand Name NBF

Model Number LV/MV/HV

Insulation Material XLPE

Type High Voltage

Application Other, Industrial,Construction Power Station,Industrial ,Underground

Conductor Material Other, copper or aluminium

Jacket PVC

Specifications

1 IEC, ASTM, DIN, BS standard
2 ISO,CCC certification
3 Response within 12 hours
4 Free Sample
5 On time delivery

High Tension Armored Cable ,SWA, Armoured PVC Power cable

Conductor for PVC Underground Cable :

Standard and Property for Using
The XLPE insulated power cable can be produced according to our factory specification with the standard IEC60502. The factory can also design and manufacture special XLPE cable according to the other standards required by the customers. They not only have excellent electric, mechanical properties, but also have powerful resistance against chemical corrosion, heataging and environmental stress. Their structures are simple. The permissible maximum operating temperature is 90C. It is convenient for using, and they can be laid with no restriction of different elevation.

The Type and Main Application for PVC Underground Cable :

Type	Designation	Type	Designation
YJV	Copper conductor ,XLPE insulated ,PVC sheathed power cable	VV	Copper conductor ,PVC insulated ,PVC sheathed power cable
YJLV	Aluminium conductor ,XLPE insulated ,PVC sheathed power cable	VLV	Aluminium conductor ,PVC insulated ,PVC sheathed power cable
YJY	Copper conductor, XLPE insulated, PE sheathed power cable	VY	Copper conductor, PVC insulated, PE sheathed power cable
VLY	Aluminium conductor ,XLPE insulated ,PE sheathed power cable	VLY	Aluminium conductor ,PVC insulated ,PE sheathed power cable
YJV22	Copper conductor ,XLPE insulated ,steel tape armoured ,PVC sheathed power cable	VV22	Copper conductor ,PVC insulated ,steel tape armoured ,PVC sheathed power cable
YJLV22	Aluminium conductor ,XLPE insulated ,steel tape armoured ,PVC sheathed power cable	VLV22	Aluminium conductor ,PVC insulated ,steel tape armoured ,PVC sheathed power cable
YJV23	Copper conductor ,PVC insualted ,steel tape armoured ,PE sheathed power cable	VV23	Copper conductor ,PVC insualted ,steel tape armoured ,PE sheathed power cable
YJLV23	Alunminium conductor ,XLPE insulated ,steel tape armoured ,PE sheathed power cable	VLV23	Alunminium conductor ,PVC insulated ,steel tape armoured ,PE sheathed power cable
YJV32	Copper conductor, XLPE insulated, steel wire armoured,XLPE insulated power cable	VV32	Copper conductor, PVC insulated, steel wire armoured,PVC insulated power cable


YJLV32	Aluminium conductor, XLPE insulated ,steel tape armoured ,PVC sheathed power cable	VLV32	Aluminium conductor, PVC insulated ,steel tape armoured ,PVC sheathed power cable
YJV33	Copper conductor, XLPE insulated steel wire armoured , PE sheathed power cable	VV33	Copper conductor, PVC insulated steel wire armoured , PE sheathed power cable
YJLV33	Aluminium conductor , XLPE insulated , streel wire armoured ,PE sheathed power cable	VLV33	Aluminium conductor , PVC insulated , streel wire armoured ,PE sheathed power cable

Conductors

The cable conductors can be made of copper or aluminium. The choice is a matter of

customer’s preference or current carrying capacity. Large size solid conductors are

made of aluminium.

Available conductor constructions:

(1)round solid conductors up to 2000 mm2 (RE)

(2)circular stranded compacted conductors up to 1200 mm2 (RM)

(3)circular conductors with shaped wires up to 2000 mm2 (RM, Keystone conductors)

(4)segmental conductors up to 2500 mm2 (RMS, Milliken conductors)

(5)oval shaped stranded compacted conductors up to 800 mm2 for external gas

pressure cables (OM)

The conductors are manufactured to meet the requirements of the relevant national and

international standards. For special applications the conductors can be made watertight.

Insulation

The insulations for low pressure oil filled cables and for conventional pipe type cables

are lapped from high quality insulating papers. Subsequently the paper insulated cable cores are impregnated

in appropriate vessels with low viscous oil or high viscous compound.

For manufacture of XLPE insulated high voltage cables, NBF cables disposes of four extrusion lines.

Highest quality standards together with latest process control equipment and combined with decades of experience ensure manufacture of cables meeting the highest requirements

and enabling development of most advanced power cable systems.

Metallic Covering

Conventional paper insulated cables require a pressure proof and watertight metallic

enclosure, acting also as metallic screen. At NBF cables both, extruded lead sheath as

well as the aluminium sheath can be applied. These types of metal sheaths are, of course,

also used on XLPE insulated cables. While the lead sheath leads to smaller dimensions,

the aluminium sheath provides high short circuit current carrying capability and lower weight.

As the XLPE insulated cables do not require an internal overpressure, they are usually

equipped with a copper wire screen. For radial moisture barrier a coated aluminium foil is longitudinally applied.

The combination with the polyethylene oversheath is called aluminium polyethylene laminated (APL) sheath.

This solution provides high short circuit capability and watertightness combined with lowest weight and smallest

dimensions.

A combination of the copper wire screen with a metal sheath is also possible. For all XLPE insulated high

voltage cables, the space between cable core and water barrier is made longitudinally watertight.

Oversheath

An extruded polyethylene sheath is provided as the standard solution. With respect

to its excellent mechanical strength it is the optimum for buried cables. If required,

a conductive layer can be provided on the outside. For special applications different

sheathing material may be used, optimized for the purpose.

Cabling and Armouring

Packing And Transportation

Wooden Cable Packing Drums

We offer a wide range of Wooden Cable Drum that are specially designed to meet the requirements of cable packing . With the assistance of these cable drums the cables can be easily transported to various destinations without causing any defect to the cables.
