Specifications
lor-coded PVC jacket single core.2.Through ULVW - 1 vertical retardant test.
3. much quantity to short times supply
Screened Control Cable KVVP2-22 4X4
Screened Control Cable KVVP2-22 4X4
1.PVC Insulation Screened Control Cable KVVP2-22 4X4 450/750v 0.6/1kv
2.CE approvered
3.Core: 2~61
4.Section area: 0.5~10
1. Standard
The product is manufactured according to the standard of GB9330Polyvingl chloride insulated control cable, IEC 60227 Polyvinyl chloride insulated cables of rated voltage up to and induding 450/750V and IEC 60502 Extruded solid dielectric insulated power cables foe rated voltages from 1KV up to 30KV
2. Applications
PVC insulated and sheathed control cable is suitable for the interconnection in controlling, signaling, protecting and measuring systems with rated voltages up to and including 450/750V or 0.6/1KV
3. Operating characteristics
1, Rated power-frequency voltage Uo/U : 450/750V or 0.6/1KV
2,Max.permissible continuous operating temperature of conductor: 70
3,The ambient temperature under installation should not below 0.If the ambient temperature is lower than 0,the cable should be preheated.
4, The bending radius of cables are recommened as follows:
Non-armoured cable : not less than 6 times of the cable diameter.
Armoured or copper tape screened cable: not less than 12 times of the cable diameter.
Screened flexible cable: not less than 6 times of the cable diameter .
4. Voltage designation
The rated voltage of the cable for a given application shall be suitable for the operating conditions in the system in which the cable is used , and is expressed in the form of Uo/U (Um)KV .Where :
Uo-The rated power-frequency voltage between conductor and earth or metallic scieen ,for which the cable designed;
U-The rated power-frequency voltage between conductors, for which the cable designed;
Um-The maximum value of the highest system voltagefor which the equipment may be used.
TYPE |
NAME |
Section Area(mm 2 ) |
|
|
|||||
|
0.75 |
1 |
1.5 |
2.5 |
4 |
6 |
10 |
|
|
|
No. of Core |
Application Site |
|||||||
KVV |
Copper Conductor, PVC Insulated and Sheathed Control Cable |
2-48 |
2-14 |
2-10 |
Permanent installation indoors, in cable ditches or pipes |
||||
ZR-KVV |
Flame Retardant Copper Conductor, PVC Insulated and Sheathed Control Cable |
||||||||
NH-KVV |
Copper Conductor, Mica tape Fire-Resistant, PVC Insulated and Sheathed Control Cable |
||||||||
KVVP |
Copper Conductor, PVC Insulated and Sheathed, Braiding Shielded Control Cable |
2-48 |
2-14 |
2-10 |
Permanent installation indoors, in cable ditches or pipes where shielding is required |
||||
ZR-KVVP |
Flame Retardant Copper Conductor, PVC Insulated and Sheathed, Braiding Shielded Control Cable |
||||||||
NH-KVVP |
Copper Conductor, Mica tape Fire-Resistant, PVC Insulated and Sheathed, Braiding Shielded Control Cable |
||||||||
KVVP2 |
Copper Conductor, PVC Insulated and Sheathed, Copper-tape Screened Control Cable |
4-48 |
4-14 |
4-10 |
Permanent installation indoors, in cable ditches or pipes where shielding is required |
||||
ZR-KVVP2 |
Flame Retardant Copper Conductor, PVC Insulated and Sheathed, Copper-tape Screened Control Cable |
||||||||
NH-KVVP2 |
Copper Conductor, Mica tape Fire-Resistant, PVC Insulated and Sheathed, Copper-tape Screened Control Cable |
||||||||
KVV22 |
Copper Conductor, PVC Insulated and Sheathed, Steel tape Armored Control Cable |
7-48 |
4-48 |
4-14 |
4-10 |
Permanent installation indoors, in cable ditches, directly buried, Be able to withstand stronger external mechanical force |
|||
ZR-KVV22 |
Flame Retardant Copper Conductor, PVC Insulated and Sheathed, Steel tape Armored Control Cable |
||||||||
NH-KVV22 |
Copper Conductor, Mica tape Fire-Resistant, PVC Insulated and Sheathed, Steel tape Armored Control Cable |
||||||||
KVV32 |
Copper Conductor, PVC Insulated and Sheathed, Thin steel wire Armored Control Cable |
19-61 |
7-48 |
4-14 |
4-10 |
Permanent installation indoors, in cable ditches, vertical shaft Be able to withstand stronger external mechanical force |
|||
ZR-KVV32 |
Flame Retardant Copper Conductor, PVC Insulated and Sheathed, Thin steel wire Armored Control Cable |
||||||||
NH-KVV32 |
Copper Conductor, Mica tape Fire-Resistant, PVC Insulated and Sheathed, Thin steel wire Armored Control Cable |
||||||||
KVVR |
Copper Conductor, PVC Insulated and Sheathed, Flexible Control Cable |
4-48 |
- |
- |
Installation indoors where flexibility and movability are required |
||||
ZR-KVVR |
Flame Retardant Copper Conductor, PVC Insulated and Sheathed, Flexible Control Cable |
||||||||
NH-KVVR |
Copper Conductor, Mica tape Fire-Resistant, PVC Insulated and Sheathed, Flexible Control Cable |
||||||||
KVVRP |
Copper Conductor, PVC Insulated and Sheathed, Braiding shielded Flexible Control Cable |
4-16 |
4-48 |
- |
- |
Installation indoors where flexibility shielding and movability are required |
|||
ZR-KVVRP |
Flame Retardant Copper Conductor, PVC Insulated and Sheathed, Braiding shielded Flexible Control Cable |
||||||||
NH-KVVRP |
Copper Conductor, Mica tape Fire-Resistant, PVC Insulated and Sheathed, Braiding shielded Flexible Control Cable |
||||||||
