XLPE Cable/ABC Cable Overhead Insulated Cable with a nominal voltage of 10KV and 35KV
Application:
Cu or Al conductor XLPE or HDPE insulated aerial cable is suitable for aerial power lines with A.C rated voltage U(Um) up to 10(12)KV and 35(42)KV
Type |
Name |
Applications |
JKTRYJ |
Soft copper conductor XLPE insulated aerial cable |
For aerial fixed installation. The soft Copper conductor cable is used as down lead of the transformer. It should be considered to keep a certain distance between cables and trees during installation. Frequent touch between cables and trees is allowed during installation. |
|
JKLYJ JKLGYJ |
Al/ACSR conductor XLPE insulated aerial cables |
|
JKTRY |
Soft Copper conductor PE insulated aerial cable |
|
|
JKLY JKLGY |
Al/ACSR conductor PE insulated aerial cables |
|
|
JKLY/Q JKLGY/Q |
Al/ACSR conductor light-duty thin PE insulated aerial cables |
It should be considered to keep a certain distance between cables and trees. Only touch for short-time is allowed between cables and trees during installation. |
|
JKLYJ/Q JKLGYJ/Q |
Aluminum conductor XLPE insulated aerial cables |
Specifications:
Model |
No. of Cores |
Rated Voltage |
|
JKLYJ JKTRYJ JKLGYJ |
1.3 |
10KV |
35KV |
JKTRY |
1 |
35~300 |
50~300 |
JKLY JKLGY |
35~300 |
|
|
JKLY/Q JKLGY/Q | |||
JKLYJ/Q JKLGYJ/Q |
1 |
10~300 |
|
Working conditions:
1. Rated voltage: 10KV, 35KV.
2. Cable installation temperature: above -20°C.
3. Max. temperature of cable at short circuit(the longest lasting time can not exceed 5 minutes):
for XLPE insulation: 250°C;
for HDPE insulation: 150°C.
4. The Max. bending radius of cable shall not be less than 20(D+d)mm.
D: the nominal overall diameter of cable;
