Product Details
| Condition | New | Type | Drum Drying Equipment | |
| Place of Origin | Jiangsu, China | Brand Name | YONGLI | |
| Model Number | YLHG1 | Voltage | 380/400/415 | |
| Power(W) | 2.2*2 | Certification | CE & ISO9001 & SGS | |
| Warranty | 1 year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Newest design drying machine for sawdust with CE approval
wood drying machine
1.Introductions of wood drying machine
- Three -pass dryer with longer mixing duration of hot air and material.
- Available raw material: mainly for powder biomass raw material, such as sawdust or grinded wood powder.
- Main applications: can be widely used after grinding process in the biomass pellete production line.
| Model | YLHG1 | YLHG2 | YLHG3 | YLHG4 | YLHG5 | ||
| Body | Inside diameter(mm) | 1700 | 2450 | 2650 | 2850 | 3700 | |
| Length(mm) | 8000 | 8000 | 9100 | 9000 | 10000 | ||
| Rotary speed(r/min) | Can be adjusted by process | ||||||
| Capacity(t/h) | 1 | 2 | 3 | 4 | 5 | ||
| Inlet temperature( ℃ ) | <500 | <500 | <500 | <500 | <500 | ||
| Raw material | Sawdust | ||||||
| Moisture(%) | 45 | ||||||
| Outlet temperature( ℃ ) | 80 | 80 | 80 | 80 | 80 | ||
| Power(kw) | 2.2*2 | 3*2 | 4*2 | 4*4 | 5.5*4 | ||
3.Features of wood drying machine
- Three-pass dryer is with high drying efficiency, heat utilization ratio and less space needed. The floor space is 30% less than single drum dryer with the same capacity.
- Support of roller ring and retainer wheel are integral cast steel structure, with high strength, stable operation, anti-abrasion and long service time.
- Convenient feeding, feeding from middle of dryer by screw conveyor or from the top according to the different materials.
- Sealed by flexble and anti-abrasion steel disc at the drum body and feeding & discharge end. It is of long service time and easy installation.
- Lifting plates installed inside the drum make the material full mixed with hot air, with low residue and high drying efficiency.
- Reasonable discharge structure that can seperate from losing and improve the utilization efficiency.
4.Attractive advantages of wood drying machine
- Non-dust workshop
- Siemens motor
- Professional service and unique custom-made design
- National patent, No: ZL201210406389
- Reasonable price
5.Pictures show: wood drying machine
spare parts: wood drying machine
Related Production line
Peeling process, Chipping process, Drying process, Grinding process, Pelletizing process, Cooling and packaging process.
It will be different according to different raw material,mositure content and size.The whole process is highly automatically controlled.
- Packaging: Depending on customers' requirement,such as iron case or iron pallet etc.
- Shipping: When the container arrived our factory, ur shipping operator and delivering equipments will be ready on time to ensure goods shipped based on Sales Order requirement.
