colorful hd SMD ph5mm led big screen clear photos p5 led screen indoor led large screen display
P5mm indoor mobile rental led display board for stage background
1.Large viewing angle;
2.Perfect color mixing effect
P5mm indoor mobile rental led display board for stage background
Led sign board:
1. High intensity,No mosaic
2. Low power consumption
3.Competitive price, super design
4. CCC,CE,ROHS,ISO
LED Display screen for stage rental service design for stage rental company who need quickly fixing the screen in stage, the important feature is all frame made aluminous to reduce the weight, and add lock in the side of frame for air-handing instal, also all rental screen should be made by SMD 3 in 1 LED to show very nearly distance view.
The control system includes video processer, it can be work with laptop, DVD player, camera digital input, S-Video, CRV and so on. It's a idea for stage to make it easy instal and play.
1. Full-color SMD technology: 3-in-1 LED package
2. Available in 1.6 mm, 1.9mm, 2.5mm, 3mm, 4mm,5mm, 6mm etc model
3. Steel and aluminum cabinet construction - corrosion resistant
4. Capable of showing audio-enabled video clips, animations, advertisements, logos, and text
5. Multiple control software options
Main Features
1. High intensity and can be adjusted, so can meet the request of the customers according
the application environment.
2. Best equality, commendably solve the problem of the mosaic, have the excellent
consistency of light
3. To pictures and character, have clear, exquisite and real display effect
4. Big viewing angle to 140 degree at horizontal line, 140 degree at vertical line,
you can see at every angle at this range, no picture change, no color excursion
5. Can repair each led lamps, so the cost of maintain is lower, and easy to repair
Applications:
Use for indoor stadium With high contrast and outstanding brightness, the full-color, full-motion technology flexibly and instantly presents up to 360 degrees of ribbon-style video, animation, adverts, and live information to fully immerse your viewers in the game-day experience.
Pixel configuration |
SMD3528 1R1G1B 3 in 1 |
|
LEDs configuration |
Red:wave length: 625~630nm;300-400mcd |
|
Pixel pitch(mm) |
5 |
|
Pixel density |
40000 |
|
Calibrated brightness(cd/sqm,nit) |
3200 nits(adjustable) |
|
Calibrated brightness proportion ratio |
R: G: B = 30%:60%:10% |
|
Color temperature |
3,500° -9,500° K(adjustable) |
|
Contrast ratio |
4,500:1 |
|
Brightness adjustment(dimming) |
100 grade auto/manual-adjustment |
|
View angle(degree)(50% brightness) |
Horizontal: 160° (80° off center); Vertical: 160° (80° off center) |
|
Readability viewing angle |
Horizontal/ Vertical: 170° (85° off center) |
|
Color capability |
4.4 trillion |
|
Refresh rate(Hz) |
>1200 Hz |
|
Frame frequency(Hz) |
>60 Hz |
|
Interface port |
DVI interface(DVI connector) |
|
Input signal |
VGA, Video, AVI, MOV, MPG, DAT, VOB etc. |
|
Protection grade |
IP65 front side/IP54 backside |
|
LED Drive |
Constant-current drive |
|
Lifetime(hours)(50% brightness) |
100,000 hours |
|
Signal transmission direction |
Horizontal |
|
Operating temperature(Celsius degree) |
-30-65' |
|
Storage temperature(Celsius degree) |
-35-70' |
|
Operation humidity(RH) |
0-95% |
|
Operation humidity(RH) |
0-99% |
|
Servicing |
Front and back serving optional |
|
Control mode |
Synchronous & asynchronous available |
|
Communication options |
Wire Ethernet, Fiber Ethernet,RF wireless,GPRS |
|
Power |
120/240 V AC single phase(50-60Hz) |
|
Maximum power consumption(W/SQM) |
800 |
|
Average power consumption(W/SQM) |
320 |
|
Screen operation mode(scan/static) |
1/8 |
|
Module configuration |
Length |
32 |
Height |
32 |
|
Module dimensions(mm) |
Length |
160 |
Height |
160 |
|
Cabinet configuration |
Length |
4 |
Height |
4 |
|
Cabinet dimensions(mm) |
Length |
640 |
Height |
640 |
|
Width |
170 |
|
Screen configuration |
Length |
4 |
Height |
3 |
|
Screen dimensions(m) |
Length |
2.5600 |
Height |
1.9200 |
|
Screen Size |
SQM |
4.9152 |
Recommend Optimal Viewing Distance: Minimum & Maximum |
Min |
3 |
Max |
68 |
|
Resolution ratio(dots/pixels) |
Length |
512 |
Height |
384 |
|
Aspect Ratio(L:H) |
1.33333 |
|
Packaging configuration |
2 standard cabinets in a packing case(1 cabinet in 1 packing case when the unit cabinet is more than 1.5SQM) |
|
Packing material |
Wooden case/carton/flight case(optional) |
|
Packing quantities |
6 |
|
Packing volume(CBM) |
2 |
|
Packing Dimensions(mm) |
Length |
745 |
Height |
845 |
|
Width |
520 |
|
Packing weight(KG) |
net |
184 |
gross |
249 |
|
1. Pre-sales service:
a) Our company can arrange professionals to conduct site installation and debugging in strict accordance with the requirements of the schemes and the original manual. If there is any special requirement, it is necessary to make changes of part installation scheme, we will coordinate with users. Our company can ensure the consistence of completion time and contracted time. Any problems caused by natural factors or man-made, we will discuss with client to find solutions.
b) Our company can train the users based on the manual. The training include system use, system maintenance and equipment protection.
2. After-sales service:
a) Service principles: response in time, solve problems as soon as possible and ensure the use.
b) Service period: In the Maintenance period of the LED screen body, free of all maintenance charges; After Maintenance period, only charge the material costs fees free of manual work fees.
c) Service scope: If the users find any problem that cannot be solved, please contact with our company, we can response in 24 hours. In order to shorten the maintenance time, Our Company will deploy some spare parts such as power and chips etc.
d) Under normal use and storage, Our Company will be responsible for the equipments.
Repair Service for LED Display Lifelong time
Usually, there are three tyeps of package design.
Firstly, we pack the LED display in the paper carton.
Secondly, we will pack the LED display in the flight case if customer request for frequent movement.
Thirdly, the favorable package method is wooden case package because of its lower cost and instant usage.
