High Brightness SMD P5mm Outdoor LED Screen LED Advertising Display
(1) SMD P5 Aluminum module
(2) High brightness
(3) Light weight and slim design
(4) Big View Angle
(5) IP68 Protect Grade
P5 HD LED display Main advantages:
1. New mask design makes LED light almost zero reflection, which ensures the screen displaying effect;
2. The cabinet of unit modules adopts to high-temperature spraying technology, the antirust function is greatly improved;
3. Module surface flatness ± 0.2mm, the entire screen has good flatness;
4.High uniformity display color;
5. For improving the service life, PCB is made by wave soldering process with the green oxygen isolation layer, which prevents the line of moisture and oxidation.
6. Service efficiency of the screen switch power supply is increased substantially, which reduces power failure rate;
7. Using fishbone bus line greatly reduces the contact problem;
8. IP65 grade for high performance waterproof and dustproof capability.
9. -25°C – 65°Cworking environment for outdoor display, adapted to the harsh environment.
| P5 HD LED display for digital commercial small radiation large viewing angle 1/16 scan | ||
| Unit Module | Item | parameter |
| Model | P5 - 16S | |
| Module size | 320mm*160mm | |
| Pixel Pitch | 5mm | |
| Pixel Density | 40000dots/m2 | |
| Pixel Configuration | 1R1G1B | |
| Package mode | SMD3528 | |
| Module Resolution | 64dots(W)*32dots(H) | |
| Max power consumption | 25W | |
| Module Thickness | 14.27mm(without magnet) 26.6mm (with magnet ) | |
| Module Weight | 0.21kg | |
| Driving Method | Constant Current Driving | |
| Scan Method | 1/16scan / 1/8scan | |
| Interface Way | HUB75-A | |
| Brightness | ≥1600cd/m2 | |
| Unit Module | dimension | 640mmx640mm |
| Quantity of Module | 16 | |
| Thermal discharge | fan 2pcs | |
| Power supply Mode | 5V/40A* 2pcs | |
| Pixel per cabinet | 128mm*128mm | |
| Thickness | 85mm | |
| Optimal Viewing Distance | 5M-30M | |
| Optimal Viewing angle | 160°(W)120°(H) | |
| Enviroment Temperature | Storage :-35℃-+85℃ work :-20℃-+50℃ |
|
| Power | Relative Humidity | 10%-95% |
| Operating Voltage | AC220V±10% | |
| Average power consumption | ≤1180W/m2 / ≤270W/m2 | |
| Max power Consumption | ≤500W/m2 / ≤800W/m2 | |
| Current | ≤20mA (Single LED ) | |
| Control system | CPU | Pentium4 or above P4 or above |
| Operate system | WIN98/2000/NT/XP | |
| Control Mode | Synchronization with PC | |
| Main technical parameter | Driving Device | IC Constant current driving |
| Refresh Rate | ≥400HZ | |
| Gray/Color | RGB each 256 grade, can display 16.7M clolor | |
| MTBF | ≥9000hours | |
| Power Switch | Automatic Switch | |
| Display Mode | 800*600/1024*768 | |
1. Pre-sales service:
a) Our company can arrange professionals to conduct site installation and debugging in strict accordance with the requirements of the schemes and the original manual. If there is any special requirement, it is necessary to make changes of part installation scheme, we will coordinate with users. Our company can ensure the consistence of completion time and contracted time. Any problems caused by natural factors or man-made, we will discuss with client to find solutions.
b) Our company can train the users based on the manual. The training include system use, system maintenance and equipment protection.
2. After-sales service:
a) Service principles: response in time, solve problems as soon as possible and ensure the use.
b) Service period: In the Maintenance period of the LED screen body, free of all maintenance charges; After Maintenance period, only charge the material costs fees free of manual work fees.
c) Service scope: If the users find any problem that cannot be solved, please contact with our company, we can response in 24 hours. In order to shorten the maintenance time, Our Company will deploy some spare parts such as power and chips etc.
d) Under normal use and storage, Our Company will be responsible for the equipments.
Repair Service for LED Display Lifelong time
| Trade terms : | 1. Payment:T/T,30% deposits before production,70% balance to be paid before delivery . |
| 2. Shipping freight are quoted under your requests . | |
| 3. Shipping port: Shenzhen,mainland China . | |
| 4. MOQ:1SQM . | |
| 5.Package : Wooden packing and flight packing . | |
| About Technology : | 1. We provide the technology training for free, which contains the operation training and maintenance training at our factory. |
| 2. We will send our engineers to your country by negotiation. | |
| 3. We provide CAD drawing on how to fix up the display for free and some other expert suggestion. | |
| 4. We will send our engineers to your place if we are expected after our negotiation. |
