Led Billboard Signs PH10 Outdoor Led Billboard Display
| Certificate: | CCC | Module Plainness: | ≤1mm |
|---|---|---|---|
| Led Packaging: | DIP346 | Control Platform: | Windows |
| Waterproof IP: | Front:IP65 | Color Temperature: | 3200-9300K |
| Working Temperature: | -30ºC To +60ºC | Working Humidity: | 20% To 90% |
Quick Viewing:
Pixel pitch is 10 mm with DIP346 led lamp;
Brightness is adjustable from 500 to 7000cd per square meter;
The led encapsulation is traditional DIP346 with unrivaled reliability;
The optimum viewing angle is 110 degree in Horizontal and 55 degree in vertical;
Led panel size W 640 x H 640 mm, W 960 x H 960mm and W1280 x H 960 mm available;
Led Panel weight is about 55kg per square meter;
Refresh rate is more than 960Hz;
Gray level is 14 bit;
IP rating: Front: IP65; Rear: IP54;
Operating temperature is from -20°to 50°;
Humidity scale is from 10% to 95%;
Detailed Description:
1. It provides the ultimate in flexibility, concave and convex, right angle displays are all available;
2. Smart cabinet design to enhance IP rating:
1) Rain getter on both sides of cabinet ensures water drain on sides;
2) Special treated cable trough hole between cabinets keeps water at the back;
2) Cabinet doors are covered by a overhang to protect water at the back;
3) Water leakage hole located on bottom of the cabinet to resist water at the bottom;
4) Air vent of the cabinet is covered by dust-proof net to protect again dust;
3. High brightness but low attenuation thanks to its reasonable current intensity design;
4. Applicable to Ocolour Test Reliability test program, verified all-weather resistance performance;
Popular Application:
Out of home digital advertisement
Led encapsulation |
DIP346 |
Led configuration |
1R1G1B |
Pixel pitch(mm/inch) |
10mm / 0.39 inch |
Red chip |
Wavelength range: 619-628nm, 5nm; |
Green chip |
Wavelength range: 461-470nm, 4nm; |
Blue chip |
Wavelength range: 522-531nm, 4nm; |
Resolution |
929dots/sq.ft (10000dots/) |
Maintenance |
Front-maintained |
Brightness: CD/sq.ft (CD/ |
>650CD/sq.ft (7000 CD/) |
Refreshing frequency: Hz |
>960 Hz |
Grey scale |
14bit |
Module pixel |
W 32 × H 16 dots |
Module size |
W 12.60 X H 6.30 inch (W 320 × H 160 mm) |
Viewing angle |
Horizontal: 110°, Vertical: 55° |
Cabinet material |
Aluminum/steel |
Lightness uniformity |
Pixel & module>90% |
Cabinet color |
Customized |
Driving method |
1/4 scan constant current |
Driving IC |
MBI5041/MBI5024/JXI5020 |
Cabinet size |
Cabinet size could be adjustable by demands |
Power supply |
85-264VAC, typical value: 110VAC/220VAC |
Max consumption |
Max.≤60.39W/sq.ft (650W/) |
Average consumption |
Ave.: 20.07-30.19w/sq.ft(Ave.:216-325w/) |
Led life time |
≥100000hours |
Mean time to failure |
≥5000hours |
Module plainness |
≤1mm |
Pixel out of control |
less than 1/ 10000 dispersion state |
Working temperature |
-30ºC to +60ºC |
Working humidity |
20% to 90% |
Waterproof IP |
lamp & top:IP65, other part:IP54 |
Protection function |
dampproof/dust-free/anti high temp/anti-thunder/ anti electromagnetic interference, etc |
Certificate |
CCC /CE/UL/Rohs/Tuv |
Hardware interface |
Standard PC network interface technology/U disc/3G |
Display mode |
24 bit true color |
Colors |
281 trillion colors |
Colour processing ability |
≥14bit |
Color temperature |
3000K ≤ TC ≤9000K, adjustable |
Brightness regulating degrees |
continuously adjustable step by step through the software |
Anty-Y correction curve |
Anti-γ correction system: 2.2-2.8 adjustable |
Image adjust |
White balance/contrasting / hue control/ Single point brightness adjustment |
Image processing |
mage noise reduction/ image enhancement/ image motion compensation/ Image color coordinate transformation processing/ Image passivation treatment |
Correction technology |
Yes |
Video mode |
AVI, WMV, MPG, MOV, DAT, VOB, MP4, FLV |
Controlling platform |
Windows |
1. Pre-sales service:
a) Our company can arrange professionals to conduct site installation and debugging in strict accordance with the requirements of the schemes and the original manual. If there is any special requirement, it is necessary to make changes of part installation scheme, we will coordinate with users. Our company can ensure the consistence of completion time and contracted time. Any problems caused by natural factors or man-made, we will discuss with client to find solutions.
b) Our company can train the users based on the manual. The training include system use, system maintenance and equipment protection.
2. After-sales service:
a) Service principles: response in time, solve problems as soon as possible and ensure the use.
b) Service period: In the Maintenance period of the LED screen body, free of all maintenance charges; After Maintenance period, only charge the material costs fees free of manual work fees.
c) Service scope: If the users find any problem that cannot be solved, please contact with our company, we can response in 24 hours. In order to shorten the maintenance time, Our Company will deploy some spare parts such as power and chips etc.
d) Under normal use and storage, Our Company will be responsible for the equipments.
Repair Service for LED Display Lifelong time
