Free shipping 1/16 Scan 3in1 RGB P3 Indoor Full color Advertising media HD LED Display Module 192*192mm 64*64 pixels
- Tube Chip Color:
- Usage:
- Model Number:
- Pixels:
- Module Material:
- Power Input:
- Module resolution:
- Module size:
- Drive mode:
- LED:
HD 3 in 1 P3 Indoor LED Display Video Wall For Billboard / Concerts / Stage
Pixel pitch:3mm,4mm,5mm,6mm,7.62mm,8mm,10mm,16mm... Application :billboard,concerts ,stage, events,stadium,advertising ,train station,shopping center,meeting screen ,airport ,mall...
Features:
a. Display video, vivid and no flashing, to achieve live broadcast.
The strongest: anti-striking, broken-resistant, and safe with special materials of macromolecule.
Wireless:displaying, driving and receiving are integrated to simplify the complex inner structure, improving its safety and stability.
Wide view angle: the perfect image can be enjoyed from any direction within the range of 160°.
Unique Structure: with 75°screen frame and fast installed connector, realize plane assembly, 15° inner or outer arc assembly, displacement assembly to accomplish arbitrary model.
Fastly heat dissipation: adopt the most advanced heat conducting technology, realizing the design of fan free, totally mute voice, high efficiency in heat dissipation. |
| Technical Parameters of P3 (3 in 1)in door LED display | |
| Usage | Indoor |
| Pitch(mm) | 3 |
| Pixel Constitute | 1R1G1B |
| LED Chips--Epistar+Silan | R:λd(625-630nm) G:λd(522.5-525nm) B:λd(467.5-470nm) R:(180-200mcd) G:(330-360mcd) G:(95-105mcd) |
| Pixel Density(dots/sqm) | 111111 |
| Module Size(mm) | 192*96 |
| Cabinet size | (W)576mm*(H)576mm*100mm |
| Viewing Distance(m) | 3-11m |
| Viewing Angle(°C) | V140, H160 |
| Average Power Consumption | 300W/sqm |
| Brightness (white balance) | ≥1800cd/sqm |
| Refresh rate | ≥2000Hz |
| Frame frequency | ≥60Hz/s |
| Average NO failure time | ≥5000 hours |
| Life span | >100000 hours |
| Working temperature | -30 °C~+60 °C |
| Driving Voltage | 220±15% or 110±15% |
| Working Voltage | 5V±10% |
| Driving Method | 1/16 |
| Display Function | Video, Animation, Graphics, other |
| Operating system | Windows (2000/XP/Vista) |
| Control distance | CAT5 cable:<100 m; Single fiber:<10 km |
