P5 Indoor Full Color Led Video Wall Display Panels , Stage Background Led Screen
1. ≤1mm surface level up, smooth video
2. Perfect quality and stability, 24/7 running
3. Front or Rear Access Service
4. 2 years warranty
5. Long lifespan up to 100,000 hours
6. Support any format of video, RF, S-Video, RGB, RGBHV, YUV, YC, COMPOSITION
1. High Definition & High Performance
More than 40000 dots per sqm, LED display can show vivid HD images in true color.
2. Vivid Picture Quality
With High refresh rate and high quality LEDs, the screen delivers excellent visual effect to audience.
3. 2 years warranty
Free replacement and maintenance for spare parts is offered within warranty period. Permanent
maintenance service is offered before product’s life expires.
4. Front or Rear access Service Available
Our many outdoor screens have been used by our clients around the world for 3-5 years and no product
issues are called.
Pixel Pitch |
5mm |
Module Size |
160mm×160mm |
Module Resolution(Pixel) |
32dots×32dots |
Pixel Density |
40000dots/m2 |
LED Type |
SMD |
Pixel Configuration |
1R1G1B |
Wavelength (R.G.B) |
R:625±2nm G:525±2nm B:470±2nm |
Drive Mode |
1/16 |
Cabinet Size |
800×640×135mm |
Cabinet Resolution |
160dots×128dots |
Brightness |
≥2000 cd/m2 |
Contrast |
≥ 4000:1 |
Viewing Angle |
140°(Horizontal )/140°(Vertical ) |
Best Viewing Distance |
4m |
Grey Scale |
10bits/1024levels |
Color Capability |
16777216 |
Color Temperature |
5000-9300K |
Maximum Power Consumption |
1000W/m2 |
Average Power Consumption |
350W/m2 |
Working Voltage |
AC 220V/110V s±15% 50-60 HZ |
Frame Frequency |
60-85 HZ |
Refresh Frequency |
240 - 1000HZ |
Brightness Correction |
Pixel, Module, Cabinet Correction |
Operating Temperature |
Static:-40°C ~+85°C Working:-20~+65°C |
Operating Humidity |
10-90% RH |
LED Lifespan |
100,000 hours |
MTBF |
≥50,000 hours |
Computer Operation System |
Win 98/ Win XP/ Win 2000 |
Video Signal Input |
RF,S-Video, RGB,RGBHV,YUV,YC,VGA, DVI, HDMI, SDI,HD-SDI ,Composite |
Video Signal Output |
RF, S-Video, GB, RGBHV, YUV, YC etc. |
Graphics Card |
DVI Graphics Card |
Control Distance |
UTP CAT5E:100m Multi-mode Fiber:500m Single-mode Fiber:10km |
Control System |
LED studio 10.0 |
Software |
LINSN / Nova/ DB-STAR |
Waterproof Level |
IP31 |
Installation |
Wall mount, hung and stand structure |
Out of Control Rate |
0.01 % |
