Home > Consumer Electronics > LED Display > Indoor LED Display > 40X9 Inch Full-color RGB LED Sign Wireless and Usb Programmable Rolling Information P3 Indoor Led Display Screen

40X9 Inch Full-color RGB LED Sign Wireless and Usb Programmable Rolling Information P3 Indoor Led Display Screen

US$ 588 - 4,888 MOQ: 1 Square Meter

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Model Number:

JC-FSI-PH3MM(rental)

Shenzhen Jingcan Opto-Tec Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name JC

Model Number JC-FSI-PH3MM(rental)

Usage Indoor

Tube Chip Color Other, 2014 new rent led display screen

Display Function Graphics

Pixels Other, 2014 new rent led display screen

Screen Dimension 384mmx384mm

40X9 inch full-color RGB LED sign wireless and usb programmable rolling information P3 indoor led display screen

Quick Details:

Pitch: P3 indoor LED video wall

module resolution: 80*80

module size; 240*240mm

cabinet size: 480*480mm

Product Description

1. High contrast: We apply SMD2121 black face LED lamps to improve the contrast.

2. High refresh rate: BAKO indoor LED display is with high refresh rate and it is suitable for various occasions for camera.

3. seamless connection: we apply die-casting aluminum cabinet and the precision is good. Therefore, it is seamless connection.

4. Slim cabinet design: For indoor LED video wall, we use slim cabinet to save space.

5. Good color uniformity: Full-depth image calibration in the factory and in the field provides for a uniform display picture.

6. Wide view angle: for horizontal, the view angle is 160°and for vertical it is 110°. This is totally enough for indoor view.

7. Real color image: There are 281 trillion kinds of color. So LED screen can show vivid and real image.

8. Low weight: For each cabinet, the weight is only 9 KG. So it is very easy for installation.

9. moire remove: We have our PCB design compatible for the high grade IC. so there is no moire.

Specification

Unit module	Pixel pitch	3 mm
	Pixel density(dots/sqm)	111111/sqm
	LED encapsulation	SMD2121
	Driving method	1/16
	Module size(mm)	240*240
	Resolution of module( dots)	80*80
Major technical parameters	Cabinet size	480*480mm
	Brightness	1300cd
	Refresh rate	>2000HZ
	Color temperature	6500K
	View angle(H/V)	160°/140°
	Grey scale	16bit
	Brightness adjustment	256 grade/ Manually/ Automatically
	Working/ storage temperature	-20℃~50℃/ -30℃~60℃
	Working/ storage humidity	10%~90% RH
	Working voltage	AC220/110V 50Hz
	Protect degree	IP43
	MTBF	>5000h
	Life span	100000h
	Input Signal	AV, S-VIDEO, VGA, DVI, HDMI, SDI, DP
	Operation system	Windows 7/XP
	Control distance	cat-5 data cable:<100m, optical fiber<15km
