Stone Cutting Machine for Granite Slab, Slab Making
US$ 18,200 - 18,300
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
TIAN JUN
Model Number:
LCZD-160
Payment & Shipping
Payment Methods:
Port of Shipment:
XIAMEN CHINA
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Stone Cutting Machine for Getting Marble Slab, Slab Cutting MachineUS$ 15,700 - 16,300MOQ: 1 Unit -
LCZQ-160/160A Stone MachineUS$ 9,400 - 10,000MOQ: 1 Set
-
Single Arm High Efficiency Multi-blade Stone Cutting MachineUS$ 16,000 - 22,000MOQ: 1 Unit
-
2014 Multi-blades Granite Gang SawUS$ 246,800 - 246,850MOQ: 1 Unit
-
TJCZ Portal Two-Way Stone CutterUS$ 27,000 - 30,000MOQ: 1 Set
Place of Origin
Fujian, China
Brand Name
TIAN JUN
Model Number
LCZD-160
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Stone cuttin machineFor granite and marble slab making
1. hydraulic up/down
2. high efficiency
3. multi-blade
LCZD-160 (hydraulic up/down) high efficiency multi-blade stone cutting machine
It adopts large-area contacting rails and double hydraulic cylinder up-and-down movement to improve the moving up speed. Overall protection of this machine has greatly enhanced stability of the machine to make sure the higer efficiency, longer life-span and lower maintenance rate.
| Technical data | |||||
| Name | Unit | LCZD-160 | |||
| Number of Blades | pc | 12(6-Φ1600, 6-Φ940) 16(8-Φ1600, 8-Φ940) 20(10-Φ1600, 10-Φ940) | |||
| Blade vertical stroke | mm | 1000 | |||
| Max. cutting size | mm | 3500*1300*650 3500*1300*850 | |||
| Main motor power | kw | 65/75/90 | |||
| Water consumption | m3/h | 16 | |||
| Dimensions(L×W×H) | mm | 8500*4000*5500 | |||
| Weight | kg | ≈9000 | |||
| Voltage/Frequency | V/HZ | 380V/50HZ | |||
| Cutting efficiency: 8 large and 8 small combination saw 24 hours cutting 300m2 | |||||
