Cloth Suit Bag, Cloth Cover Bag Making Machine

Cloth Suit Bag, Cloth Cover Bag Making Machine thumbnail-1
Cloth Suit Bag, Cloth Cover Bag Making Machine thumbnail-2
Cloth Suit Bag, Cloth Cover Bag Making Machine photo-1
Cloth Suit Bag, Cloth Cover Bag Making Machine photo-2
US$ 5,000 - 20,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Machine Type:
Bag Forming Machine
Bag Type:
Other, cloth cover bag
Contact Supplier Request Quote Chat Now
Ruian Tiansheng Packing Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Machine Type Bag Forming Machine
Bag Type Other, cloth cover bag
Material Plastic
Computerized Yes
Place of Origin Zhejiang, China
Brand Name Tiansheng
Model Number TS600
Voltage 220V
Power(W) 4kw
Dimension(L*W*H) 3*1.2*1.75m
Weight 700kgs
Certification CE and SGS
Warranty one year
After-sales Service Provided Engineers available to service machinery overseas

cloth suit bag, cloth cover bag making machine



cloth suit bag, cloth cover bag making machinecloth suit bag, cloth cover bag making machine







Cloth suit bag, cloth cover bag making machine

cloth suit bag, cloth cover bag making machine







Features of cloth cover bag making machine

1. Electrical sensors track the material feeding,

it will stop automatically when material run out.

2. Equipped With one photocell for tracking the printed film,

it can make printed bags in one track, two or four tracks for

non-printed bags.

3. The sealing knives have double sides, one

line sealing for flat bag, two lines sealing for

T-shirt bag.

4. Receiver part equipped with Static electricity treating

device and hot pins, to make bags stack neat after cutting.

5. Main driving motor is frequency inverter

control, the bag making speed is adjustable.

6. All the electrical parts adopts Chinese famous brand.

7. Bag length is controlled by stepper motor (servo motor optional), high precision.







cloth suit bag, cloth cover bag making machine

Model

TS600A

TS700A

TS800A

TS900A

TS1000A

TS1200A

Max bag width

520mm

620mm

720mm

820mm

920mm

1120mm

Max bag length

2000mm

Bag thickness

0.008-0.1mm

Speed of bag making

40-100pcs

Main motor power

1.1kw

1.1kw

1.1kw

1.5kw

1.5kw

1.8kw

Feeder motor

2 pcs

Electrical sensor

2 pcs

Photocell

1 pcs

Sealing knives

2 pcs

Stepper motors

1 pcs

Sealing method

Heat sealing

Cutting blade

1 set

Cutting method

Cold cutting

Static eliminator

1 set

Machine weight

800kgs

850kgs

900kgs

1000kgs

1100kgs

1300kgs

Machine dimension(M)

3×1.2×1.75

3×1.3×1.75

3×1.4×1.75

3×1.5×1.75

3×1.6×1.75

3×1.8×1.75







cloth suit bag, cloth cover bag making machinecloth suit bag, cloth cover bag making machinecloth suit bag, cloth cover bag making machine    cloth suit bag, cloth cover bag making machine







Free spare parts with cloth cover bag making machine

No.

Spare parts

Quantity

1

Spring

100pcs

2

Teflon tape

2pcs

3

Blade heater

4pcs(a set)

4

Thermocouple

2pcs

5

Tool box

1pcs







cloth suit bag, cloth cover bag making machine







cloth suit bag, cloth cover bag making machine







cloth suit bag, cloth cover bag making machine







cloth suit bag, cloth cover bag making machine







link for more plastic bag making machine

cloth suit bag, cloth cover bag making machine







In order to quote you exact plastic bag making machine, please offer us following details:

1-What kind of plastic bag do you want to produce?

2-What is the max width of plastic bag do you want to produce?

3-What is the productivity of machine do you want?







OUR SERVICE:



1. Installation Services



 Installation Services are available with all our new machines. We can send our technician

to your factory to help you install your purchased machines from our factory. Of course,

your factory need to supply the round trip tickets food, hotel and salary to our technician.





2. Clients Training Services



We advise each customer can send your own technician come to our factory to learn how

to operate our machines. We will let our technician teach and train your technician hand by

hand till he can operate our machine by himself.





3. After Sales Service



Our machine guarantee time is one year.



We will send many easy broken spare parts in the tool box together with machines.



If any parts broken, please take a pictures or a videos to us.







 cloth suit bag, cloth cover bag making machine
