Chinese Manufacturer Andes Measure The Heavy Proof Water Bag
Proof load water bag is specifically designed to use water in place of traditional solid weights for loading test. hissystem allows for a much safer and practical method for load testing for most of the lifting equipments and load bearing structures, such as deck cranes, pedestal cranes, offshore cranes,and general purpose cranes.
HEU Water bag is made of special materialwhich comes ready with quick-set water inletand outlet with hoses,gatherslings ,
shackles, and master link. The use of proof load water bags is recognized world wide as an efficient and cost effectivesolution for the offshore annual crane test.
HEU proof load water bags are available in the following capacities : 1T, 5T,10T, 12.5T, 20T, 25T, 30T & 35T. We may build to your special and unique requirements. Please call and discuss with us.
Model |
Volume(m3) |
Diameter(m) |
Length(m) |
Empty bag weight(kg) |
HEU-20t |
20 |
3.6 |
5.4 |
160 |
HEU-25t |
25 |
3.8 |
5.8 |
180 |
HEU-30t |
30 |
4.0 |
7.0 |
200 |
HEU-35t |
35 |
4.4 |
7.5 |
250 |
Item |
Quantity |
Remark |
water inlet assembly |
2sets |
Including 4 pcs hose clamps |
water outlet assembly |
1set |
Including valve and coupling |
Outlet hose Φ100mm |
2mtrs |
/ |
Water bag |
1set |
Wooden case packing |
Gather sling |
8pcs |
SWL 4T |
50mm to 60mm adapter |
2sets |
/ |
Rubber rope |
8pcs |
/ |
shackle |
4pcs |
SWL12.5T |
Inlet hose Φ60mm |
2rolls |
20m/roll |
Master link |
1pcs |
29T |
1.Packing details:Standard export wooden case
We can also pack according to customer's requirements
2.Delivery details: Within 7 days after the total payment
