aerial work platform Nissan high-altitude skylift truck
Nissan 4X2 high-altitude skylift truck
1. We are the manufacturer.
2.OEM is OK .
3. ISO9100 certificate.
| Packaging Details: | Nude/ Ro-ro ship / Bulk transport / Container packing / SKD / etc. and it can be offered according to your request. |
|---|---|
| Delivery Detail: | Within 10 to 25 days after receiving your deposit by T/T,L/C |
| Technical parameters | |||
| The totalmass(kg) | 5495 | Curb Weight(kg) | 5105 |
|
Rated the quality of(kg) |
Chassis Model | ZN1050B5ZM | |
|
Approach / departure angle(°) |
Front overhang / rear overhang |
||
| Dimensions(mm) |
Compartment dimension(mm) |
||
| Number of axes | 2 | Maximum speed | 115 |
|
Tire Specifications |
7.00R16LT 12PR | Number of tires | 6 |
| Front track | 1568 | Rear track | 1458 |
| Wheelbase | 3349 | Axle load | 1895/3600 |
| Number of spring | 6/5+5 | Type of fuel | Diesel |
|
Emission Standards |
Euro3/Euro4 | ||
| Engine parameters | |||
| Engine Model | ZD30D13-4N | Engine Manufacturer | |
|
Engine Displacement |
2953 | Engine power | |
|
Chassis Description |
4X2 chassis, flat cab with air conditioner, 5 speed gear box, 5 cylinder diesel engine, with left/right hand drive optional.Steering control , oil brake |
||
|
Modified Description |
1.height of working:10-26m,360°all rotation,three folding arms,single hydraulic cylinder,rated load of cage:200-250kg. 2.1 ton stretch hook,four hydraulic oil cylinder that are adjustable,without emergency power unit. 3.Equipped with two-way balancing valve,ectrical control operation,two sets of operating system. (1set platform pilot switch and 1 set pilot switch in the cab); |
||
| Component |
Equipped with two-way balancing valve,ectrical control operation,two sets of operating system. (1set platform pilot switch and 1 set pilot switch in the cab); |
||
| Purpose |
Convenient moving,used in narrow roads and streets.Aerial work platform can be used in aloft working of electricity,street lamp,municipal administration, gardens,transportation and so on. |
||
| Product advantage | reasonable price,multiple functions,easy operation | ||
