Specifications
1.HT steel sliting machine2.Certification: ISO 9001:2000
3.Guarantee:12 months
4.Usage: coil slitting
5:Color: an
steel sliting machine
main parameter of aluminum coil slitting machine
| 1 | Material of frame |
(high grade) 80mm H shape steel welding |
| 2 |
Thickness of middle plate |
12mm |
| 3 | Step of forming roller |
4steps |
| 4 | Diameter of shaft |
61mm |
| 5 |
Drive type |
drive by chain |
| 6 |
Chain |
19.05 mm (high grade) |
| 7 | Bearing |
6210 (high grade) |
| 8 | Reducer |
5# (high grade) |
| 9 |
Line speed |
about 10-12 m/min |
| 10 |
Feeding width |
1000-1200mm |
| 11 |
Suitable coil thickness |
0.35-0.50mm |
| 12 | Cutter | 3sets |
| 13 | Weight of machine | about 0.9T |
| 14 |
Appearance size of machine |
1.5m (length)*1.0m (width) *1.2m (height) |
| 15 |
Electrical parts |
DELIXI or CHINT |
coil slitting machine, steel sheet slitting machine, metal slitting machinery,
steel sliting machine
Certification of Hutong roll forming machine factory
Note:We can customize the design and fabrication on the particular type of machine according to the request of custmer.
Welcome your inquiry. We are sure you will get good machine quality and best service.
