Help CenterFLOOR-TYPE MILLING AND BORING MACHINE MODEL TK6916
Related Products
-
TX68 Horizontal Boring and Milling MachineNegotiableMOQ: 1 Set -
TXM170A Vertical High Precision Boring, Milling and Grinding MachineNegotiableMOQ: 1 Set
-
TXM260 Vertical Fine Boring Grinding and Milling MachineNegotiableMOQ: 1 Set
-
T716A Vertical Fine Boring MachineNegotiableMOQ: 1 Set
-
UNIVERSAL-FACING-AND-BORING-HEADNegotiableMOQ: 1 Set
Specifications
1.CE,standard2.No.1 quality in the market
3.High quality to price ratio
4.spare parts support
This series product has the function of boring holes, drilling holes, milling and cutting, five faces machining can be done when equipped with a high accuracy rotary working table, a right- angle milling head and so on. It’s widely used in the fields of metallurgical, energy sources, electric power, mine, engineering mechanism, and military engineering industry, ship-building. The spindle adopts high-accuracy rolling bearings to support. The X, Y, Z axis equipped with rolling lead screw transmission, compensation equipment of spindle box, heat balance protection system, and double gears framework which could eliminating clearance. This machine has a function of completely self-diagnosis, which operates convenient and agile. All kinds of special accessories such as angle milling heads, special milling heads, facing plates, can be equipped according to customers’ requests.
Main Parameters:
TYPE ITEMS |
TK6916 |
|
Boring spindle diameter |
160 |
|
Boring Spindle Feeding Range |
0.5~3500 mm/min |
|
Milling arbor end diameter |
260 |
|
Spindle taper |
ISO50(7:24) |
|
Specification of Shank |
ISO50(7:24) |
|
Spindle speed |
2-1250 |
|
The end Diameter of Milling Spindle |
φ340 mm |
|
Max. Torque of Boring Spindle |
6800 N.m |
|
Max. Feeding Resistance of Spindle |
35000N |
|
Ram section size |
480×520mm |
|
Transverse travel of vertical column (X) |
8000mm |
|
Feeding of Vertical Column |
0.5~3500 mm/min |
|
Vertical travel of spindle box (Y) |
4000mm |
|
Feeding Speed Range of Headstock |
0.5~3000 mm/min |
|
Travel of boring spindle (Z) |
1200mm |
|
Travel of ram (W) |
1200mm |
|
Superposition Traveling(W,Z) |
2400 mm |
|
Feeding Speed Range of Ram |
0.5~2000 mm/min |
|
|
Feed speed range |
X |
1-6000mm/min |
Y |
1-6000 mm/min |
|
Z |
0.5-4500 mm/min |
|
W |
0.5-4500 mm/min |
|
CNC system |
SIEMENS 840D |
|
CNC Main Spindle |
6 Axis |
|
Joint axes |
4 Axis |
|
Capacity of A.C.T. system pc. |
40/60/80 |
|
Main Motor Power |
71Kw |
|
Overall Size |
9000×4712×8695mm(Approx.) |
|
Machine weight |
115 T |
|
Model: HTK250 CNC Heavy Rotary Table
Worktable Dimension: 2500×3000mm
The Hight of Worktable: 1300mm
Max. Workpiece of Worktable: 2000mm/3000mm
The Linear Traveling of Rotary Table: 2.5~2000mm/min
Linear Travel Speed Range of Rotary Table: 0.001~0.55r/min
Rotary Speed Range of Rotary Table: Siemens 840D
CNC System: Siemens 840D
Total weight of Rotary Table: 25000kg
Overall Dimension: 5744×2810×1300mm
