Specifications
EDM zinc coated wire electrode1.Size:0.1-0.3m
2.Material:CuZn35
3.Tolerance:-0.002mm
4.Smooth surface,
EDM coated wire electrode
1.Size:0.1-0.3m
2.Material:CuZn35
3.Tolerance:-0.002mm
4.Smooth surface, low impurity content
Specifaction
Type |
Diameter (mm) |
Tolarance (mm) |
Tensile strength (Mpa) |
Surface treatment |
Conductivity (%) |
|
Hard or Semi hard |
0.10 |
+0, -0.002 |
980min |
Paraffin free |
22min |
0.15 | |||||
0.20 | |||||
0.25 | |||||
0.30 | |||||
|
Soft |
0.10 |
+0, -0.002 |
442min |
Paraffin free |
25min |
0.15 | |||||
0.20 | |||||
0.25 | |||||
0.30 |
Advantage
- Faster cutting speed, higher cutting accuracy compare to plain wire.
- Precision tolerance (-0.002mm), high regularity
- Advanced heat treatment techniques endure stable tensile strength and protect wire from breakage.
- Superior straightness and roundness makes self-threading process easier.
- High purity copper wire (≤65%) are used.
- Packed by carton box (excluding plastic element), more environmental friendly
BUNOL A 900 can be used on all EDM machines. It is recommended for standard applications in the areas of moulds, for the manufacture of cutting tools or general mechanics parts. In this case BUNOL A 900 constitutes the best compromise in terms of its cost, precision and the quality of its
Packing
5KG/roll, 4rolls per carton
carton weight=20kg
Carton size;340mm*250mm*195mm
Volume per Carton = 0.35*0.26*0.18*=0.0166 CBM
1000KG wire will be packed in 50carton Total Volume =0.35*0.26*0.18*50=0.83 CBM
A full 20 foot container can load 26 / 0.83 =21.5 21.5*1000 = 21500 KG
