Help CenterUntra Wire Cut EDM Brass Wire Electrode Manufacturer WSH092
Related Products
-
EDM Brass Wire Electrode For Wire Cutting MachineUS$ 8 - 15MOQ: 1000 Kilograms -
Brass EDM Wire Electrode 0.30mmUS$ 7.5 - 9MOQ: 1000 Kilograms
-
Soft EDM Brass Wire 0.25mm For EDM Wire Cut MachineNegotiableMOQ: 4 Kilograms
-
Brass EDM Wire Electrode ManufacturerUS$ 7.8 - 10.5MOQ: 1 Ton
-
Sodick Wire Cut Brass Wire Electrode 0.15mmUS$ 7 - 15MOQ: 1000 Kilograms
Untra EDM Wires for Sodick and Charmilles
1.Available dimention: 0.10mm-0.30mm
2.Tolerance: =0, -0.002mm
3.Weight: 5kg/spool
Company Profile
Yin Sihai precision mold represents innovative know-how and highest quality product in terms of WEDM-LS and Spark erosion.
Looking for partner for direct manufacturing of EDM consumable?
We produce all the necessary nonrepairable items and expendable parts for your start hole drilling machines, electric discharge wire machines and cavity sinking EDM machines.
Our long experience with the security that we offer only high quality products at a reasonable price.
Timely delivery is self-evident.
Our technically competent team is always available.
You are in search of EDM filter, wires or wire guide?
Don't worry, we can make you an interesting offer.
Have a word with us.
Specificaction
Type |
Diameter (mm) |
Tolarance (mm) |
Tensile strength (Mpa) |
Surface treatment |
Conductivity (%) |
|
Hard or Semi hard |
0.10 |
+0, -0.002 |
980min |
Paraffin free |
22min |
0.15 | |||||
0.20 | |||||
0.25 | |||||
0.30 | |||||
Features
High dimentional accuracy
Diameter tolerence is kept to +0 ~ -0.002mm and circularity within 0.001mm.
Outstanding straightness
We test each spool for curling and torsion and pride ourselves on the stable automatic wire threading performance or our product.
Stable mechanical properties
Tensil strength, elongation, breaking load, etc. are checked with automatic measuring equipment to ensure stable quality.
Ultra-smooth surface
A unique quality control system involving special diamond wire drawing dies and lubricating oil ensures that KH wire has an extremely smooth surface, free from irregularities, dirt and scratches.
High reliability
Automatic measuring equipment ensures rigorous control of manufacturing batch.
Packing
5KG/roll, 4rolls per carton
carton weight=20kg
Carton size;340mm*250mm*195mm
Volume per Carton = 0.34*0.25*0.195*=0.0166 CBM
1000KG wire will be packed in 50carton Total Volume =0.35*0.26*0.18*50=0.83 CBM
A full 20 foot container can load 26 / 0.83 =21.5 21.5*1000 = 21500 KG
